Page 3 · Read text
www.butkus.us
your Ansco Memqr 12.8
You will find that the Memar Camera is
easy to use, compact to carry and produces
suplrior picturei. This 35mm camera is
equipped with an Agfa Color-Apotar f/2'8
coated lens in a Pronto shutter. It is syn-
chronized for flash and with its automatic
winding device, self-timer, and optical
viewfinder, it is a versatile camera for pic-
tures anywhere, anYtime.
The Memar is easY to oPerate, but be-
fore using it, read the following directions
carefully, trying all the working parts as
yoo r"td. Whett you have become thor-
oughly familiar with its operatio-n,Ioad the
with one of Ansco's fine 35mm
"u-"itfilms (see page 12) and enjoY taking
pictures with this superior camera'View original page 3Page 5 · Read text
www.butkus.us comero ports 1. -b,xposure Counter 2. Automatic Winding Device 3. Cable Release Socket 4. Shutter Release Button 5. Accessory CliP 6. Viewfinder 7. Film Type Indicator 8. Film Rewind Knob 9. Diaphragm Aperture Scale 10. Diaphragm Setting Ring 11. Shutter Speed Setting Ring 72. Depth of Field Scale 13. Distance Setting Ring 14. Locking Slide 15. Flash Connector 16. Self-Timing Lever 17. Tlipod Socket 18. Rewind Release ButtonView original page 5
Page 6 · Read text
rhe viewfinder
The Memar camera is equipped with an above the subject to compensate for the
optical-type viewfinder. Holding the cam- difference in view between the lens and the
era to the eye, you will see the area which viewfinder. For correction when taking
will appear in the picture. When focusing vertical pictures, turn the camera slightty
on objects closer than 7 feet, sight slightly in the direction of the viewfinder.
4
www.butkus.usView original page 6Page 7 · Read text
www.butkus.us
focusing
The focusing ring is the foremost ele-
ment of the lens mount and is identified by
the figures 3.5 through o (infinity)' When
the distance from camera to subject has
been determined, turn the focusing ring
until that distance figure is opposite the
diamond-shaped index mark on the sta-
tionary lens mount. Estimate distances as
r""otit"ly as possible so your pictures-will
be sharp and clear. When taking pictures
isirom 3 to 10 feet from the subject, it
very important that the distance be esti-
mated accurately (or better yet, measure
the exact distance) because of the limited
depth of field. For distant views, set the
camera at infinitY ( o )'View original page 7Page 9 · Read text
www.butkus.us
The shutter of a camera determines the
length of the exposure. The Pronto shutter
on the Memar has mechanically regulated
speeds of ll21t};' to 1/200th of a second,
plus B (for time exposures). It is also syn-
chronized for flash at I l25th second (see
page 19). The shutter speed is set by turn-
ing the thin milled ring so that the desired
speed is opposite the diamond-shaped
index mark on the stationary lens mount.
The shutter is released (the exposure
made) by pressing down on the shutter
release button. Be sure to hold the camera
level and steady and press the release but-
the shutter ton with a firm, slow pressure.View original page 9Page 10 · Read text
qufomofic winding device
After each exposure, grip the straight ter release button will remain locked until
edge of the winding lever with the right the film is wound.
thumb (shown in picture at right) and pull Intentional double exposures can be it to the right as far as it will go. Be suro it goes the full distance or the shutter will made by pressing the rewind release but-
not be ready for the next exposure. This ton after the first exposure and winding an
action winds the film, cocks the shutter exposure. This will add an extra exposure
and counts the exposures, so after each to the counting dial, but will not advance
winding, the camera is ready for the next the film. Make the final exposure by de-
exposure. This automatic winding feature pressing the shutter release button in the
prevents double exposures since the shut- usual manner.
I
!. ,. .View original page 10Page 12 · Read text
self -f imer deprh of field The Memar has a self-timing mechanism Depth of field is that distance between which allows about a nine second delay in the nearest and farthest points of sharp exposure to permit the photographer time focus. With the diaphragm set at f 14, and to get in the picture. With the diaphragm the distance setting at 6 feet, everything opening and shutter speed set, move the- frorn 5'2" to 7'2" will be in acceptably lever at the bottom of the lens mount to sharp focus. flowever, with the diaphragm the left as far as it will go. Release the closed down to f 116, everything from 3'8" shutter in the usual rnanner and 'after to I5'8" will be in focus at the same dis- about a nine second delay, the picture will" tance setting. Therefore, it should be be taken. The self-timer will not work on remembered that if existing light permits, "B," since time exposures are not me- the diaphragm should be closed down for chanically pre-determined. sharper pictures. r0View original page 12
Page 13 · Read text
www.butkus.us
A depth-of-fietd scale is conveniently Io-
thedeprh of field scole cated on the stationary lens mount at
front of the camera. On each side of the
center index mark are identical rnarkings
which indicate the various diaphragm set-
tings from f/2.8 through f 122.
With the camera set at any particular
distance, the depth of field for any specific
diaphragm opening can readily be deter-
mined. The depth of field is that distance
between the two lines representing the
diaphragm setting being used.
If the indicated depth of field is insuffi-
cient to cover the proposed subject, close
down the diaphragm, but don't forget to
compensate for this smaller opening by in-
creasing the exposure time.View original page 13Page 15 · Read text
www.butkus.us
1
film rype indicqtort
A film type indicator is incorporated in
the top of the rewind knob. The indicator
is set as a reminder of the kind of film in
the camera. For example, if Anscochrome
Daylight Type film is used, set at COL/D-
Set the indicator when loading the cameia.
With the rewind knob pulled all the way
out, prdss the index finger of your left
hand against the serrated edge under the
knob. With your right hand, turn the top
of the knob so the proper setting shows in
[' the opening.
tView original page 15Page 16 · Read text
To open the camera, pull down on the down the film magazine with your left
Iatch at the bottom of the left side of the hand, pull out a short length of film. fnsert
camera and swing out the hinged back. the end of the film into the slot of the
Turn the winding spool until the slot is winding spool, engaging the tooth of the
on top. Do not attempt to remoue this spool slot in the second full perforation of the
from camera. small tongue. Turn the winding spool with
Set the counter disc at A by pressing in your thumb until about fu inch of the fullthe center and turning counterclockwise. width of the film is visible. Close the back
Pull out the rewind knob (marked R on of the camera firmly.
top) and insert the film magazine with the Press the shutter release button and
emulsion side (light side) of the film wind the film; repeat until three "expo-
toward the lens. Set the film type indicator sures" have been made and the film
as described on page 1-3. counter is on 1. The film is now in position
Push in the rewind knob and holding and the first picture can be made.
looding fhe cqmero
www.butkus.usView original page 16Page 17 · Read text
www.butkus.us
outdoor exposures
Exposures outdoors vary according to
the existing light and the type of film
being used. With the excellent coated lens
of the Memar and the versatilitY of
Ansco's fine 35mm films, pictures can. bp
taken almost anytime, anywhere. When
using Anscochrome or SuPer Ansco-
chrome, keep in mind that your subject
should be weII lighted and heavy shadows
should be avoided.
" The following table is given as a guide
for determining the correct exposure.
l5View original page 17Page 19 · Read text
www.butkus.us indoor exposures The illumination for pictures indoors angle, and the fill-in light should be placed should be from either floodlamps or flash- close to the camera. lamps. Floodlamp illumination is a con- The following table was computed from venient, economical source of light for these lighting diagrams and will serve as a indoor pictures. A good basic setup calls basic guide to help you determine thefor two number 2 photoflood lamps in good correct exposure. The table is based on Reflectorflood (or two reflectorsquality colored light subjects against average the accom- as in shown placed #2lamps), re- colors Darker walls or surroundings. source light main Thepanying diagrams. should be directed downward at a 45" quire an increase of one or two stops.View original page 19
Page 20 · Read text
BASIC FLOODTAMP EXPOSURE TABrE AT r/2s SECOND
Based on Two 500-Watt (3200K) Lamps in Good Quality Reflectors
Main Light 6' L2'
Fill-in Light 8rz, 18',
Super Hypan f lL6 f t6.3
Super Anscochrome Tungsten* f t8: f lz.a
xWhen using photoflood lamps (3400K), use an 81A filter.
For exposures longer t}rran ll25th of a used to minimize the chance of jarring the
second, the camera must be mounted on a camera. The cable release screws into the
tripod, or other firm, level support. It is top of the shutter release button.
also recommended that a cable release be
l8View original page 20Page 21 · Read text
www.butkus.us
flqshlomp exposures
To get the full enjoyment from your lamps-SM, SF, #5, 25, #8 and M2
camera, try making flash pictures. It is with an adapter.
always fun to take pictures indoors-at When using flashlamps indoors, either
parties, of the children at play, of special Anscochrome or Super Anscochrome can
occasions. be used. The use of Daylight Type color
The Memar is synchronized only at film requires blue flashlamps---Super An-
Ll25th second unless SM or SF lampsbre scochrome Tungsten Type requires clear
used, when Il25 or 1/50 second becomes flashlamps. IJse flash illumination out-
possible. The Ansco lJniversal Flash Unit doors, too, to fiIl in deep shadows.
(JN206) is recommended for all-around The following table is based on the use
ease of operation and compactness. Just of the Ansco Flash Unit which has a
fasten the camera to the bracket and plug polished reflector. For other type flash
the tip of the cord into the flash connector units, follow the manufacturer's recom-
(No. 15. fig. 1). Do not use force as rough mendations. Please bear in mind that the
treatment will damage the connector. The unit must have a 3mm continental type
Ansco Flash Unit takes all bayonet type connector to fit on the Memar camera.
l9View original page 21Page 23 · Read text
www.butkus.ususing rhe
guide numbers elecfronic flosh
To find the conect exposure, divide the Your Memar f 12.8 carnera can be used
guide number by the distance from the with high-speed electronic flash. Since the
flashlamp to the subject; the resulting filtration and exposures may vary, the
figure will represent the lens opening re- following guide numbers are suggested as
quired. Example: The guide number for a basic.
#5B lamp with Anscochrome Daylight
Type at Ll25 is 95. The subject is 12 feet
away, therefore, 95 +L2:7.9, use f/8.
Beam Candle Power Second Rating 1800
Watt-Second Rating 100
Exposure Guide No.:
Super Hypan L27 190 225
Anscochrome Daylightx 2L 34 42
Super Anscochrome Daylight* 42 60 85
*IJse an 81A filter.
2lView original page 23Page 24 · Read text
unloqding fhe comero When the final exposure has been made, the film must be rewound into the maga- zine before the camera is opened and the film removed. Do not advance the film beyond the last exposure since the film might become detached from the maga- zine and cannot be rewound. To rewind the film, hold down the small button on the bottom of the camera and-turn the rewind knob in the direction of tripod socket the arrow. Continue turning until you feel a lessening of the tension, indicating the The tripod socket is located in the cen- fiIm has been released from the take-up ter of the bottom of the camera. It is used spooI. not only for attaching the camera to a Pull down on the locking lever and open tripod, but also.for attaching the carrying the back of the camera. Pull up the rewind case to the camera and the camera to the knob and the magazine can be removed Ansco Flash Unit. easily from the camera. 22View original page 24
Page 25 · Read text
www.butkus.us
memor cqrrylng cqse
Protect your Memar camera from dirt,
rain, dampness, by keeping it in an Ansco
Memar Eveready Carrying Case-it is
genuine top-grain cowhide. Since the Iens
and other front elements of the Memar
have no self-protective covering, it is even
more important to protect it from hard strap and an additional length can be shoulderknocks. added to make it a convenient
The Memar case has a short carrying carrying case. Your dealer will have this Memar
Carrying Case-ask for the JN445.View original page 25Page 26 · Read text
flosh unif
As mentioned earlier, you'll get much
more enjoyment from your Memar camera
if you can use it around the clock. Buy an
Ansco Flash Unit and complete the versa-
tility of your camera.
It will accept all bayonet type lamps
and takes two size C batteries or a battery
capacitor cartridge. ft also has an exten-
sion outlet for multiple flash pictures.
Your dealer has the Ansco lJniversal Flash
Unit-JN206.
cqmero core
Your Memar is a fine precision instru- It is recommended that you make ament. Given proper care, it will give you record of the serial number of your camera
years of service. Clean the front and rear for your own protection. Fill in the Ansco
elements of the lens often with a cleon, Guarantee card and send in the registra-
soft iintless cloth. Blow out the back of the tion. Ansco will send you a free roll ofcamera each time you load it to be sure 35mm Anscochrome Film upon receipt of
there are no dust particles or lint. the card.
24
48 Printed in U.S.A. C12407View original page 26Related documents and language editions
