Braun Paxette Super II BL User manual

User manual for Braun Paxette Super II BL. 27 pages in German. Read the original PDF, download or print a copy without registration.

27 pagesGerman5.0 MB PDF
Braun Paxette Super II BL manual cover
Read the manual Original PDF
Download PDF
Loading your manual…Open PDF directly

Document details

Brand
Braun
Model / document
Braun Paxette Super II BL
Document type
User manual
Language
German
Pages
27
File size
5.0 MB
Category
Film cameras
Document date
Not specified in catalog

Search available document text

Find a term, then jump to its page in the original PDF. Image-only pages may not be searchable; check the PDF for exact wording and diagrams.

Page 2 · Read text
May I be permitted to introduce myself ?    and I have been built in the CARL BRAUN
                                   Camera Works in Nuremberg, Germany. Before
My name is the                         being sent out into the wide world as a perfect
                             and first-class camera, I passed through many
suPER .]Fmxette rrBL     pairs of buey hands all intent on improving and
                                         checking my many fine qualitiee. Now it's entirely
                               up to you how well you exploit my capabilities.
                                      This small booklet will tell you all you want to
                               know about me and my internal mechanism. One
                                          thing I would ask, though, before using me for
                                       the first time, please carefully read the contents
                                   of this emall booklet .       it  certainly will be
                                 worth your while. All of my efforts and my
                                               strivings will be to solely bring you pleasure;
                                                    I trust that we will soon be good and, I  hope,
                                           inseparable companione.
                                      Hoping to remain your very obedient
                             SUPER.]FMXEIftEIIBL
View original page 2
Page 3 · Read text
www.butkus.us





To open the camera
Release the milled locking ring on
the camera base by turning it  to
the left. The back of the camera
can then be slid ofl.
View original page 3
Page 4 · Read text
Venmo @mike-butkus-camera  Ph. 2083
PayPal Name  Lynn@butkus.org      www.PayPal.me/lynnbutkus
View original page 4
Page 5 · Read text
www.butkus.us





                   To insert the film

                          Raise the film caesette retaining lever ae
                             far as it will go, and insert the caeeette
                            into the film chamber so that it engages
                            in the teeth of the rewind knob. Then
                         swing the retaining lever outwarde and
                           over the projecting spool end.
View original page 5
Page 6 · Read text
www.butkus.us




Open the film pressure plate and pull out
the trimmed end of the film far enough
to be inserted into the slot of the take-up
spool. At the eame time ensure that the
lug on the take-up spool hooks on to the
film perforation. Next, manipulate the rapid
wind lever until both sprockets of the film
transporter engage in the film perforation.
(If there is noticeable resistance in ad-
vancing the lever, pres6 the release).
Lastly, ewing the film pressure plate back
into the closed position,
View original page 6
Page 7 · Read text
Digitally signed by Mike Butkus
                                                                                         DN: cn=Mike Butkus, o=Butkus camera manuals,
                                                                                                    ou=butkus.org, email=mike@butkus.org, c=US            Mike Butkus Date: 2022.12.26 14:55:05 -05'00'
To elose the Camera
To close the camera the back should be insorted between the eamera housing and front
plate and the locking ring tightened by turning it to the right.
View original page 7
Page 8 · Read text
www.butkus.us

The Exposure Counter
The exposure counter reads backwards
from 36 to  l,  indicating each time the
number of unexposed frames still available.
After the film hae been inserted and the
camera closed. eet the counter at the red
dot near the figure 36 by turning the
toothed wheel which ie positioned just
below the maker'e name. Advance the
film twice (each time advancing the rapid
wind lever ltlz  times until a  definite
resistance is felt). and the film counter
should then read 36.
View original page 8
Page 9 · Read text
l0   The Rapid Winder
         'l'he shutter winding mechanism,
       film transport and film counter
      are coupled and operated by
     means of the rapid wind lever.
     Advance the lever as far  as
       possible, then release  it, allowing
           it to spring back. Then advance   www.butkus.us
           it approximately half way until
     a noticeable resistance is  felt.
     You may transport the film also
      by a number of short movements
      of the lever to the right until
      the resistance is felt. The film is now transported, the shutter cocked, the exposure counter
       correctly set and your Super-Paxette II BL is ready for the next shot.
     Film type rerninder
       After having inserted the film it is advisable to set the type of lilm on the type reminder disk, i. e.
       for Color-Artificial Lisht Film CK           '  for Color-Daylight Film CT
      for Negative-Artificial Light Film NI(     for Negative-Daylight Film NT
      for Black-and-White Film the black-and-white  field
View original page 9
Page 10 · Read text
www.butkus.us

To unload the Carnera                                                                                   t1
When the exposure counter showe figure 1. this means that the entire length of the film
has been oxposed.
To wind back the film, pre6s the rewind push button, and turn the rewind lever
continuously in the direction of the arrow. (like the rapid winder !). Just before the
rewinding operation is completed, a more marked resistance will be noticeable, indicating
that the end of the {ilm is still held by the take-up spool. A few more turns will wind the
film completely into the cassette. The camera can then be opened and the film changed.
Important: The rewind button must remain depressed throughout the rewinding operation.
View original page 10
Page 11 · Read text
12   Loading and Unloading Drill

      Loading the                                  Unloading the
         S U PE R . ]FMXEIIE  II BL      suPER .lPuxette  rr BL
         l. Open the camera                      1. Prees down rewind button
     2. Insert film cassette
                                              2. Turn rewind knob in direetion of arrow
        3.. Attach film to take-up spool
     4. Close the camera                     3. Wind the entire film into cassette
     5. Set the exposure counter
                                              4. Open the camera
     6. Advance the rapid wind lever twice
     7. The camera is ready for the first shot     5. Take out casgette

      )<- )€ )€ )+  x- )+  )<- )+  -x- )+     )< )< )<- )+ )€ )< )+ )€   )<-
View original page 11
Page 12 · Read text
www.butkus.us

Checking the Film Transport                                                                                                    1.3
This can be done at a glance. Once the film has been
inserted, the film transport indicator which is visible in
the recese adjacent to the rewind lever ehould move in
the direction of the finder aperture.
If the indicator does not move while the film is being
transported, check to ensure that the film has been
properly inserted into the camera.

Checking the Rewinding
To check the rewinding action, release the locking
stud during the rewinding operation. If the mechanism
is functioning properly a very definite resietance will be
noticeable. If no resistance ie felt, thie mean6 that the
film has been pulled out of the cassette and cannot be
wound back. This fault can only be remedied by
opening the camera in a darkroom.
Important: Do not attempt to force the film or the
perforation of the film will tear. When continuing  to
rewind, prese in the locking stud again,
View original page 12
Page 14 · Read text
www.butkus.us

      How to Use the Range Finder                                                                    I5
         In the middle of the light circular
          area you will see a double image of
        the subject sighted. By turning the
 I





                                                                 focussing ring these two contours should
                                                be made to coincide; in this way the
I                                                           exact distance to the eubject is esta-l;
                                                               blished and the lene focussed.
View original page 14
Page 15 · Read text
l6                                    The Built-in Exposure Meter
                                                                             l.  Apertures
                                              2. Exposure times
                                              3. ASA-Speeds
                                              4. DIN-Speeds
                                              5. Follow-up Indicator
                                              6. Exposure meter needle
                                              7. Small setting knob for DIN and ASA
                                                           degrees
                                           B. Knurled ring for setting follow-up
                                                                indicator
     Through its system the  built-in exposure meter of the Super Paxette II BL offers most
      accurate measurementB. Only a small turn on the knurled ring will set the red follow-up
       indicator over the white exposure meter needle. That is all for an exact measurement and
      the values can be read  off the scalee I and 2"
View original page 15
Page 16 · Read text
www.butkus.us

          Instruetions for IJse                                                                          17
+           Setting the film epeed:

        The ASA and DIN valuee are shown in the openings 3 and 4.
+                         Setting ranges: ASA (3) blue figures on black ground 10 . 3200
 r                            DIN (4) white figures on black ground lZ0- 360
        The eetting of the film speed, which is given on the film packing, is done by turning tho
            Plexi.disc on the little knob until the desired ASA or DIN value is brought into register
 I        with the index arrow. Every individual ASA value (blue figure and bluo arrow) and DIN
?)       value (black arrow and white figure) can be eet.





                                                            /t
         -X- -x- )< t+ )<  -).- )+ t+  )+ *     -),+- ->+ t6  ,€. ?< -)< -'< -)€ ?* )e  )+
View original page 16
Page 17 · Read text
lB    Metering

                                                                                                                     6     To measure the prevailing light conditions, point the camera in direction of the object to
     be photographed and set the red follow-up indicator (6) exactly over the white exposure
      meter needle (5) by turning the knurled ring (B). With this manipulation exposure time
     and aperture values are recorded and one of these combinations can be set on the camera
       ehutter. The measured values can be controlled any time by looking at the two pointers.


      Hints on Taking Photographs.

      Object Measurement
      This method of measurement  is the most popular of all and in moet cases sufficient. The
       light reflected from the object ie meaeured hereby, in other words, measuring is carried
                                                                                                                        D     out from the point where the photograph is being taken towards the object being
      photographed.
      However,  if the motiv to be photographed ie containing extreme light or dark components,
         it is advisable to take close-up measurements of thd most important lightest and darkest        .
       parts. The values will then be added up and the result devided into halves.
View original page 17
Page 18 · Read text
www.butkus.us


          Example:                                                                                     t9
?           I st Meaeurement         Aperture ll          L/60 sec.
        I          2 nd Measurement        Aperture 5.6         L/60 cec.
+         Total                    Aperture 16.6           l/I20 sec.    Aperture      1/60 eec.                                                                            -

        The elose-up measurement will aleo be made when a certain subject or person is the
        main component of the photograph, and the fore- and background ie unessential,  i. e. for
            portraits, objects of art, etc. In a case like that take  the measurement at a distance of
         about 30-40 cm (12-16"), but take care that your own ehadow is not darkening the object.
       The meaeurement has to be made from the same  direction as later on the exposure
           is made.

       When taking outdoor photographs, always remember  not to have too much sky within the
         measuring sphere, as rrrong values might result.
View original page 18
Page 19 · Read text
20    Colour photographs
       Perfect colour photographs can only be obtained when the camera shutter and the exposure
      meter work in porfect harmony, and the film is very carefully developed. At the moment,
     no standard system of measuring the speed of colour filme ie available, which means
      that only a comparison speed ie usually given on the film pack, i. e. "expose the
     same as . . ." With the object of finding out how the exposure meter, the camera and
       film work best together, we would suggest that three trial photographs be made of the same
       object but with three different lens apertures (f/nos.)
      Photograph no. l; with the aperture shown on the exposure meter,
      Photograph no. 2; with the next smaller aperture,
      Photograph uo. 3; with the next larger aperture.
     Make a careful note of the details of each photograph so that, after the film is developed,
     you can determine which method gave the beet resulte.
      In case of doubt, it is better to expose negative film longer than given and eo-called
       revergal film shorter than given on the exposure meter.

                                Exposure time
                               The exposure time is set by positioning the red spot
                              on the knurled ring of the shutter oppoeite the required
                                               time.
View original page 19
Page 20 · Read text
www.butkus.us

The Lens Diaphragm                                                                        2l
The lone aperture or diaphragm is set by
means of the front ring on the lens. Bring
the dot into register with the black line
at whatever setting is required.
Note: Aperture 2,8 high speed      little                                    -depth of field. Aperture 16 slow speed                                          -great depth of field.

The Delayed Action Release
The setting lever hae to be puehed from
X to green V. Thie can be done only
when tho ahutter is cocked.
Attention: When setting V ie ueed, the
ehutter eetting B cannot be used. After the
delayed action mechanism hae run off, the
eetting lever goee back to X automatically.
View original page 20
Page 21 · Read text
22





                                              www.butkus.us

     Depth of Field Ring
     The depth of field or depth of definition compriees the zone from the foreground to the
      background of the picture which is sharply defined in the reproduced image. This area or
      depth varies according to the aperture chosen, that is to Bay, a large aperture (f/2.8) gives
       less depth of field and a small aperture (f/16) gives a greater depth of field.
     with the SUPER - ]FmXgttg   rr BL the depth of field for every photograph
      can be easily read off the depth of field ring which is between the focussing ring on the
       lens and the shutter speed setting ring; this repeats on the left and on the right of the
       setting mark the range of apertures,
View original page 21
Page 22 · Read text
www.butkus.us


                                                                                          23





Changing the Lens
The lens should be screwed firmly home into the lene
panel in a clockwise direction. The central dot on the
red engraved depth of field ring should be just below
the honeycombed window when looking on the camera from
above. Remove the lens by unscrewing  it in the opposite
direction. When screwing the lenses in and out care
ehould be taken that only the milled ring, bearing the
depth of field scale, ie moved.
View original page 22

From the M. Butkus archive. Original publisher and archive notices are retained.
Check the model and edition against your equipment.

PDF verified 2026-10-10.
