CHINONwww.orphancameras.com
cM-4
SPEGIFICATIONS

o Type:35mm SLR compact camera with LED type light o ASA Range:25 - 1600 (DlN 15 - 33) with safety lock.
measuringsystem. o Film Advance:Single stroke in an arc of 13Oowith 25o
o Picture Format:24 x 36mm stand off.
o Lens Mount: Chinon UniversalBayonet Mount. o Film Counter:Automatically"S" indicatesnumber ofo Mirror: Large,Quickreturn, shocklesssystem. exposures and resets to when camera back
o Shutter:Seiko MFC metal focal plane shutter. is opened.
o Shutter Speeds: 1 sec. - 1/1000 sec., "Bl' o Film Rewind:Foldingcrank tYPe.
o Viewfinder:Fixed eye-level pentaprism,central split o Accessory Shoe: Hot shoe type with X sync.
imagewith microprismcollar and ground glass. o Action Lamp: Red LED illuminateswhile the shutter
o ViewfinderMagnification:O.87x (@SOmm,o ). operates.
o Viewfinder VisibilitY:92%. o Synchronization:Strobe Sync. at 1/60 sec.
o Exposure Meter: TTL,Centerweighted full aperture o Power Source:Two 1.5V silver oxide G-13 batteries
systememployingone siliconblue photo cell, 3 step (5-76 type).
exposureindicatorwith 3 LED's. o BatteryTest: Built-in with LED indicator.
o ExposureRange:EV + 2(F/1.9, 1 sec.)to EV + 18 o Accessories:Multi-coatedlenses,Auto electronic
(F/16,1/1OOOsec.)- ASA1OOF/1.9 lens. flashescarrying case, and many more.
o Meter ON/OFF Switch: Meter switch is activated when o Body Dimensions:135.5(W) x 86.0 (H) x 50.5 (D) mm.
shutter releasebutton is pressed,meter remainson for (5.33"x 3.78" x 1.99").
several secondsafter finger is lifted off releasebutton. o Body Weight:455 grams (16.05 oz-1.
STANDARD PACKAGING WITH
F/1.7 MC LENS #23003 AVAILABLE AS FOLLOWS: VIEWFINDER
PRODUCT PRODUCT 1. Over exposure Red LED
NUMBER DESCRIPTION NUMBER DESCRIPTION 2. Correct exposure Greed LED l o
24871 CM-4 Body 23011 CM-4 with SOmm t/1.9 lens 2 o 3. Under exposure Red LED
26200 50mm f /1.7 MC lens 23OO3 CM-4 with t/1.7 MC lens 3 o 4. Split image rangefinder
28815 Snap-infront lens cap 23OO7 CM-4 with t/1.4 MC lens 5. Microprism collar
(49mm) 23001 CM-4 with 45mm f /2.8 lens 6. Ground glass
28880 Shoulder straPwith Pad and 24871 CM-4 Body only " " D rings
Rear lens cap
Body cap
Two G -13/S-76 batteries
Instructionbook
Film speed window (ASA/DIN) Hot Shoe
Film advance lever Film rewind knob/ back cover opener
Shutter speed dial
Frame counter

Aperture ringShoulder strap eyelet
Depth of field scale
Shutter release button/ Focusing ring
exposure meter switch
Action la

Lens lock release lever

Viewfinder eyepiece
Exposure indicator LE D's/
battery check lamp
SProcket teeth - Film p(essure plate
Film chamber Take-upspool
Shutter Film chamber cover
Film rail Film guide rail
www.orphancameras.com
Rewind knob
Battery compartment cover
