Page 4 · Read text
OONDENSED          Details   ATTACHING NECKSTRAP      LENS CAP
 INSTRUCTIONS      on page   Remove neckstrap and wire loops    To remove:
 1. lnsert battery       5                              f rom plastic bag. Pry end of wire      Depress protruding tabs
                                away  f rom loop and insert             simultaneously and pullcap away
2 Load camera       6           separated end into eyelet on         from lens.
                                camera body. Keep feeding wire
 3. Set ASA  f ilm speed   9             into eyelet by turning loop until      To attach:
                                rounded portion of loop can be       Depress protruding tabs, press
 4. Advance film to first  6                            f reely moved in camera eyelet        cap against  f ront opening of lens
        f rame                                                                          barrel and release tabs.
                                 Thread neckstrap into wire loop
 5. Push down         10         and secure it by pushing double-
   exposu re meter                 headed stud into "buttonholes"
   switch, set sh utter                      in strap. Repeat procedure on
   speed, and adjust                  other side of camera.
   f/stop ring until
   needle is centered            NOTEr lnsert wire loop carefully
                                          to avoid scratching camera.
 6. Observe subject     14
   through viewfinder
7. Focus              12
8. Depress shutter     14
    release
                                                                     &
Read entire booklet
for details


                            www.butkus.us
View original page 4
Page 5 · Read text
LOADING BATTERY
A mercury battery (Mallory PX-625    Clean battery before inserting
or equivalent) powers the built-in     and thereafter at regular intervals.
exposure meter. lt is supplied with    Wipe both sides with a rough
the camera, either installed or          material to remove deposits.
packed separately in the camera      Average battery life is about one
box.                                      year. Since the battery may
                                    develop a leak, remove it before
To install battery:                   the camera is stored.
Using a coin, unlock batterY
compartment cover by turning it
counterclockwise 90 deg rees
(Fig.1). Remove cover. Place
battery in compartment with Plus
side up (Fig.2). RePlace cover.
View original page 5
Page 6 · Read text
LOADING CAMERA
Use 20- or 36-exposure 35mm  f ilm         lf it does not go back all the way,       4. To make sure  f ilm has been
 in standard magazine. GAF@  f ilms     turn knob until  it does.               loaded properly, operate  f ilm
are available for making color         3. Insert end of  f  i lm into slot in       advance lever (Fig. 7) until  it
slides, color prints, or black-and-      take-up spool (Fig.5). Place           locks. Now turn rewind knob
white prints.                     thumb lightly over film on b'ottom     clockwise untila resistance is felt.
                                     sprocket wheel and operate  f ilm     Do not force it. Keep observing
To load camera:                  advance lever until upper                                   f  i lm rewind knob; it should turn
1 . Pu ll out  f  i lm rewind knob           sprocket wheel also engages   f ilm    counterclockwise every time
(Fig.3) until camera back is              perf orations and  f  i lm is secu rely      the film is advanced, Depress
released, then swing camera back    wrapped around take-up spool        shutter release whenever the film
open all the way.                        (Fig.6). When the film advance      advance lever locks. Operate  f ilm
2. Keep  f ilm rewind knob pu lled        lever locks,  f ree it by depressing      advance lever untilfigure "1" is
allthe way out, insert magazine        the shutter release. Close camera     opposite the pointer in the
into chamber with protruding end     back.                              exposu re cou nter wi ndow
towards bottom of camera
(Fig, 4), Push in  f ilm rewind knob.





                            www.butkus.us
View original page 6
Page 7 · Read text
EXPOSURE COUNTER
(Fig.8). Do not press shutter        The number of exposures already    The next higher  f igure moves to
release when the figure "1"         made is indicated by the numbers     the index line every time the  f ilm
is opposite the index mark.               in the exposure counter window      advance lever is operated. When
                                      adjacent to the  f ilm advance lever.     the camera back is opened, the
Camera is now ready for the  f irst      As there is no space to show every     counter automatically returns to
exposure.                          number, some  f igures ar.e indicated    "S" (start).
 lf the  f ilm rewind knob does not       by dots. Each dot represents the
turn while the film advance lever is            f igure following the one before  it.
being operated, the camera was        ln Fig.9 for example, the dot
not loaded properly. Either the         next to the  f igure " 1" stands for
f ilm became detached  f rorn the                     f igure "2", the following dot
take-up spool, or the sprockets        (adjacent to index line) for
did not engage the perforations.       figure "3".
Open camera back, remove and
reload film; follow steps 2,3, and
4 carefully.
View original page 7
Page 8 · Read text
UNLOADING THE CAMERA                              SHUTTER SPEED SETTING
 Unload camera when (with a            3. Turn rewind crank clockwise. A    The figures on the shutter speed
 2O-exposure roll of film) the red       tension is felt as the film is being       dial indicate  f ractions of a second.
   f igure "20"* is opposite the index     rewound into the magazine. Stop    The figure 125,tor example,
 line in'the exposure counter           turning the rewind crank when the     indicates a shutter speed of 1/ 125th
 window.                             tension is relieved, indicating          of a second.
 Un load a 36 exposu re roll of  f ilm        that all the film has been returned    The "8" setting is used when a
 when the red  f igure "36"* is             to the magazine.                                                                                                      f onger than one second exposure
 opposite the index line.                 4. Open camera back by pulling         is req.uired. The shutter will
                                     out rewind knob all the way.          remain open as long as the shutter
                                                                                                                                 f ilm cartridge.               release is held depressed. Do not open camera back until    5. Lift out
 the unloading procedure has     Have film processed without    To set the shutter speed, turn dial
 been completed,                  delay.                                 untilthe desired figure is lined up
 Steps for unloading camera:                                                with the white index line adjacent
 1. Unfold rewind cr:ank.                                                           to the shutter speed dial on the
                                                                                   1O for 2. Depress rewind button on                                         camera body. In Fig.
 camera bottom all the way.                                              example, the shutter is set for a
                                                                                                   1/ 125th of a second exposu re.



*After the 20th or 36th picture one or more
  f rames may still be available. These  f rames
 may be utilized by operating the film advance
 lever after the red figure 20 or 36 has been
 lined up with the index line in the exposure
 counter. Pictures may then be taken until
 a resistance during the operation of the
  f ilm advance lever indicates that the end
 of the  f ilm has been reache.d. Do not force
 film advance lever beyond that point.
 While this procedure provides one or more
 additional exoosures per roll, it is not'
 recommended as the  f ilm may become
 separated  f rom the spool. The separated
 film cannot be rewound,  its removal
 from the camera reouires a darkroom                             www.butkus.us operation.
View original page 8
Page 9 · Read text
FILM SPEED SETTING
 The ASA speed of the  f ilm is           locks into place.
  specified on the box or in the        Due to the lack of space on the
  instruction sheet packed with the       dial, some film speed numbers
  film.                                  are represented by dots. The
  Pull up ring around shutter speed     following chart shows the ASA
  dial and rotate it until the ASA*       and DIN numbers represented by
  index of the  f ilm is aligned with         dots.
 the line at the center of the ASA
 window on the shutter speed dial.
  In Fig. lO for example, ASA 100
 has been set at the index line.
 When the ring is released, the
 selected ASA speed automatically


                    ASA Speed
        800 :  : 400 ? ? 200 :   : 100 : 64. 40. 25. 16 . 10
                                                                        r        ttttttttltttttt   tt    i  i r-r
           640 500 320 250 160 125 B0 50 32 20 12

                        DIN Speed
        30..27      ! ? 24 ?.21   r19.17.15.13.'11             29ililtttttrr28  26 25   23 22 20 18 16 14  12

*The    same instructions apply to  f ilms cali-
 brated according to the European DIN speed
 rating system. Line up the DIN  f igure with
 the index line under the window marked
 "DtN".
                                                                       el
View original page 9
Page 10 · Read text
EXPOSURE
The camera features a match-         then counterclockwise, unti    I         This will permit the centering of
 needle type semi-automatic CdS      needle is centered, as shown in       the need le.
exposure system. For accurate        Fig. 1 1.                      When the needle remains below
exposures the user has only to        5, Push up exposure meter switch    the horizontal position (Fig. l4)
center the needle in the                to return lens diaphragm to         even after the f/stop ring is set at
viewf inder, as shown in Fig. 11  .       automatic operation.                  the largest lens opening, turn the
                                  Exposures will now be accurate.       shutter dial to a slower speed to
To center needle:                 Turn on exposure meter and          allow the centering of the needle.
1. Push down switch shown in        re-center needle whenever a          For example,  if at a 1 / 125 second
Fig. 12 to turn on exposure         change occurs in subject              shutter speed and an t/ 16lens
meter.                                               bri ghtness or   i  I lumi nation.           opening the needle is above the
2. Set desired shutter speed.                   lf the needle stays above the           horizontal position (as in Fig. 13),
3. Observe subject thro'ugh the        horizontal position (Fig, 13) even     resetting the shutter speed to a
viewf inder.                                after the f/stop ring is set at the       1/250th of a second or  f aster
4. Turn f/stop ring,  f irst clockwise,    smallest lens opening, turn         speed will bring the needle below
                                       shutter dial to a faster speed.        the horizontal position. The needle

                                                                                14

                                                                                  ;
                                                tt
                                                                                                         I                                  ''{u+'(,t \




                            www.butkus.us
View original page 10
Page 11 · Read text
can then be centered by turning       backgrounds. Aim the camera at
     the f/stop ring.                        the most important part of the
                          f f at a 1/125th of a second shutter      subject (the face in the case of a
     speed and the largest lens opening     portrait)  f rom a distance of about
     the needle remains below the           six inches and center the needle;
     horizontal position (as shown in      then return to the original camerat
     Fig. 14), resetting the shutter to a      position and make the exposu re.
     1/60th of a second or slower
I    speed will raise the needle above     When the pictures are
     the horizontal position;  it can then    consistently over- or
     be centered by turning the f/stop      underexposed, the film may
     nng.                              be more or less sensitive than
I   andlf eventheatslowestthe largestpracticallens openingshutter      correctedits rated speed.by usingThisa canhigherbe easilyor
    speed the needle remains below       lower ASA (or DIN) speed than the
     the horizontal position, the light      one printed on the  f ilm box or in
      level is too low to provide             the instruction sheet. Use a higher
    adequate exposure. Change to a     ASA number to correct for
     faster  f ilm (with a higher ASA         overexposure and a lower ASA
    number) or use  f lash.               number to correct for under-
                                         exposure. For example,  if pictures
     Since the CdS electric eye          made on a ASA 100  f ilm are
    measures the entire image area, a      consistently overexposed, set ASA
    background that is much brighter    speed at 125 or 160, depending on
      or darker than the principal            the degree of overexposure.  lf
     subject may cause an exposure                     f ilms are underexposed, set ASA
      error. A close-up reading will            at 80 or 64.
     minimize the effect of such
I





                                                                                                                                              11
View original page 11
Page 12 · Read text
EXPOSURE METER RANGE     FOCUSING
     Virtually all situations encou ntered   Observe subject th rough                   is focused for subjects at a
      in average use fall within the           viewfinder. Turn focusing ring        distance of 4 feet  f rom the
    operating range of the exposure                  f irst in one direction, then in the      camera.
    meter. When the few seldom used     opposite direction, until image is
                                                                                                                                                                                                                                                                                         f ilm,          fi lm speed/shutter speed              sharpest. The brighter microprism    Note: When using inf rared
    combinations that are outside this     area in the center is provided to               f irst focus lens on subject, then
    range are set on the camera, a red              f aci litate   f ocusing.                     align the figure on the distance     flag appears in the viewf inder       The distance scale may also be       scale adjacent to the red t mark
     (Fig. l5). The appearance of the      used for focusing. Estimate or        with the red dot at the right of
    red  f lag indicates that the meter is    measu re the camera-to-subject      the t mark.
    not operating, necessitating the      distance in feet or meters, then
    use of a separate exposure meter.     turn the focusing ring to align     DEPTH OF FIELD
   The following table shows the         the figure representing that          "Depth of  f ield" designates the
   ASA  f ilm index and shutter speed      distance with the red I mark.         near and far limits of the area
    combinations that are within the        In Fig. 16, for example, the lens      that will be sharp in the picture
    operating range of the exposure                                                        (in  f ront of and beyond the
    meter:

     Film Speed                    Shutter Speed Range
     Up to ASA 100                From 1 sec to 1/1000 sec
         ASA 2OO                 From 1/z sec Io 1/ 1000 sec
         ASA 4OO                 From 1/q sec to 1/ 1000 sec
         ASA 8OO                 From 7a sec to 1/ 1000 sec



                               www.butkus.us
12
View original page 12
Page 13 · Read text
subject). Depth of field is                (after focusing) the approximate     opening selected for taking the
     controlled by the lens opening       depth of the area that will be          picture is t/16. The first "16" is
      (f/sto.p):  it increases as the lens      sharp in the picture. Locate on       under the 7 on the distance scale,
    opening is made smaller.             the depth of  f ield scale the pair      while the second " 16" falls just
    The depth of  f ield can be checked     of  f igures that correspond to the     a little short of 30, indicating that
     visually, or it can be read off the       f/stop selected for taking the         objects between 7 and 28 feet
     dept"h of  f ield scale adjacent to        picture. The figures appearing                      f rorh the camera will be in sharP
    the t mark on the lens barrel.        above the pair of figures on the       focus.
     For a visual check in the              distance scale indicate the near
     viewf inder, push down exposure      and far limits of the depth of field.
    meter switch. This closes the                                     f n Fig. 17, for example, the lens
    diaphragm to the lens opening           is focused at 10 feet and the
     set previously with the f/stop
     ring. lmage sharpness can now
    be observed.
    The depth of  f ield scale indicates





?




 I

i





                                                                                                                             13
View original page 13
Page 14 · Read text
TAKING THE PICTURE         SELF.TIMER                 USING FLASH
     After the lens is focused and the      The self-timer enables the           Use  f lash when the exposure meter
    needle in the viewf inder is           photographer to get into the           indicates that the existing light
    centered, take the picture by           picture. Use a tripod or place            level is too low for providing
    depressing the shutter release.       camera on a  f irm su pport. Get        adequate exposure (when the
   To prevent camera motion, press     camera ready  f or exposu re.          meter needle cannot be brought
    release softly, with an even         Move self-timer lever                    to the horizontal position even by
    pressure of the  f inger. Wherever      counterclockwise, as far as it will      using the largest lens opening and
    feasible, use a tripod when the       go (Fig. 18).                          the slowest practical shutter
    shutter speed is 1/30 second or        Start self -timer by depressing              s peed).
    slower.                                shutter release, then take position     Electronic  f lash and conventional
                                                    in  f ront of the camera. Exposure                f lash units using  f lashbulbs or
                                                     will take place approximately 8                   f lashcubes may be used.
                                    seconds after shutter release has     The camera has a hot shoe
                                   been depressed.                       (accessory shoe with built-in
                                                                                                                                                                                                   f lash contact) and two standard
                                                                                    P.C. outlets. one marked "M",
                                                                                the other "X".





                               www.butkus.us

14
View original page 14
Page 15 · Read text
Electronic and conventional  f lash     IMPORTANT: Do not use P.C.         for 0,68,26, and 268  f lashbulbs,                                                                                                                 ((M"units having a foot with built-in        cord and hot shoe of  f lash units      plug the P.C. cord into the
contact may be used without a        equipped with both.                    outlet and use a 1/60 second or
connecting cord. Just slide the                                                   faster shutter speed.
foot of the  f lash unit into the         The two P.C. outlets on the camera   Use the guide number system to
                                                                                                                                                                                                                  f lash exposure*. Findaccessory shoe all the way. As the      (Fig.19 ) accept the P.C. cord plug    establish
hot shoe has "X" type                  or  f lash units.                        guide number for speed of  f ilm
synchronization, it can be used        Plug electronic  f lash units into        being used in the instructions
with electronic flash at a 1 / 125         outlet marked "X" and use 1 / 125     supplied with  f lash unit or
second or slower sh utter speed.      second or slower shutter speed.                 f lashbulb.
With AG-1 , AG-1B, AG-38, M-2,       ForAG-1, AG-18, M-2, M-28
M-2B  f lashbulbs and  f lashcubes                 f lashbulbs and allf lashcubes,
in conventional   f lash units, use a      plug flash unit into outlet marked
1/30 second or slower shutter         "X" and use 1/30 second or
speed.                               slower shutter speed.





                                             *So                                                        called "automatic" electronic  f lash units
                                                 provide correct exposure without calcula-
                                                       tions. Follow instructions provided with
                                                  the unit.
View original page 15
Page 16 · Read text
FILTER SIZE               CHANGING THE LENS
   To arrive at the f/stop to be used,     The lens accepts Series Vll  f  i lters     Before lens is removed always
    divide the guide number by the          in 52mm diameter x .75mm pitch      disconnect exposure meter by
    distance in feet between subject       screw-in mounts, or 54mm slip-on    pulling up switch (Fig.2o).Keep
   and  f lash. For example, with a       mou nts.                             turning lens counterclockwise
    film having ASA 64 speed, a f lash                                      (shown in Fig.20) until it is
                                                                                                                                                                                                                                            f rom the camera body.    unit with a guide number of 32      FILM PLANE INDICATOR          separated
           f or that  f ilm, and a f lash-to-subject     In certain types of work  it is         To replace lens, insert threaded
    distance of B feet, a lens opening      necessary to know exactly the       end into opening in camera body
    of  f /4 will provide correct exposure    location of the  f ilm plane. The       and keep turning lens clockwise
   because:                     mark on the camera top                 until  it is firmly seated. Do not   32 (guide nur ' -                                                      -'                     indicates  f ilm position.                force  it.
                                                                   The screw mount of the camera  ffi:4(tt4).                                                                           accepts a wide variety of Pentax
                                                                  and Practica type lenses and
                                                                                accessories.





                               www.butkus.us

16
View original page 16
Page 17 · Read text
CAMERA CARE
The GAF Single Lens Ref lex         lmportant:
Camera is a precision instrument.     The original bill of sale (dated sales
Used with care, it will provide            slip with name and address of
yedrs of service. Protect the            dealer) is now accepted as proof
camera  f rom dirt, rain, dampness,      of purchase for establishing the
and excessive heat. Avoid touching    warranty period. No warranty card
the lens. To clean lens, breathe           is provided. To help identif icatiorr
on it, then wipe  it gently with a           in case of loss or theft, keep among
soft, lintless cloth or tissue. Do not    your personal records the camera
use eyeglass tissues as they          model designation (GAF L-CM) and
might damage the lens coating.        the serial number appearing on
lf anything goes wrong, do not         the camera back, at the right of
try to repair  it. Take it to a dealer       the viewf   i nde r eyepiece.
or send  it to the nearest GAF Photo
Equipment Repair Center shown
in the list on page 18.





                                                                                                                  17
View original page 17
Page 19 · Read text
Film and shutter wind:           Dimensions (body onlyf  :Sing le-stroke rapid-wind lever      Width 149 mm     (s%in.)
                                                                                     (33/+ in.)with 20 ready position and 134      Height 95 mm
                                                                                 (21/a in.)operating swing              Depth 65 mm
Film frame counter:             Weight (body onlyf  :
Automatically indicates number of    850 gr. (30 oz)
exposures- returns to "S" (start)
when camera back is opened
Self timer:
Variable delay to I seconds
Film rewind:
Folding crank type
Accessory shoe:
Standard accessory shoe equipped
with electronic contact (so called
"hot shoe") for X synchronization
Flash sync:
"Hot shoe" plus "M" and "X"
P.C. outlets- "X" sync at 1/125
second or slower shutter speed
Power source:
1.35 volt mercury battery
 (Mallory PX 625 or equivalent)

    \                                                                                 1(





                                                                                                                         19
View original page 19

From the M. Butkus archive. Original publisher and archive notices are retained.
Check the model and edition against your equipment.

PDF verified 2026-10-10.
