Mamiya PRISMAT PH User manual

NOMENCTATURE





                                                                    www.butkus.us



1. Cocking Lever                       8.  Photocell Window
2.  Shutter Button                       9.  Synchroflash Terminal
3.  Focusing Ring                     10. MXV Selector
4.  Shutterspeed Dial                  11. Lens Catch
5. Aperture Dial                     12. Backlid Catch
6.  Eyepiece                         13. Rewind Crank
7. Filmspeed (ASA) Dial                    L4.. Exposure Counter

www.butkus.us

     15. Cartridge Chamber                 20. Sprocket Release
     16. Sprocket                               2I.  Synchroflash Terminai
     17. Take-Up Spool                    22. Accessory Clip
     18. Distance Scale                     23. Strap Eyelets
     19. Depth of Field Scale                24. Tripod Socket





Mike Butkus                              Digitally                                                                    DN:email=mike@butkus.org,Date:cn=Mike2022.12.26signedButkus,by15:16:00Mikeo=ButkusButkusc=US-05'00'camera manuals, ou=butkus.org,

Venmo @mike-butkus-camera  Ph. 2083
PayPal Name  Lynn@butkus.org      www.PayPal.me/lynnbutkus

BEFORE TOADING FOR PICTURE-TAKING

  Film-loading is done in very much the same manner as with other 3S-millimeter miniature
cameras. However, because the MAMIYA PRISMAT  is a single-lens reflex camera of special
design and construction, its principal features and its workings will first be explained.
  VIEWFINDER AND FOCUSING
  Because the \4AMIYA PRISMAT is a single-lens reflex camera, it has no separate view-
finder. The light entering the main lens is deflected upward by a hinged mirror inside the
camera to form an image on a ground-glass screen which is visible through the eyepiece
(6) and pentaprism in true orientation. There is interposed between the hinged mirror
and the pentaprism a Fresnel lens and condenser to give uniform brightness to the entire
viewfinder field.  There is also interposed a prismatic coupled rangefinder so that focusing
of the MAMIYA PRISN'{AT can be accomplished speedily and accurately by means of a
split-image focusing zone at the center of the field of vision.
  When a subject is sighted through the eyepiece, there will be seen within the clear center
circle a rectangle bisected by a horizontal line. If the portions of the subject, on which
focus is to be adjusted, failing within the bisected rectangie are not in true vertical align-

www.butkus.us

ment, the camera is
out of focus. Turn
focusing ring  (3)
and bring the parts
enclosed by   the
upper and lower
halves of the rec-
tangle   (focusing
zone) into correct alignment. The distance between the camera and subject then can be
read off the distance scale (18).
  When focusing, be sure that your eye is at dead center of the eyepiece (6), and that the
portion of the subject, which must be brought to correct focus, falls squarely over or in the
center of the focusing zone. This caution is particularly necessary when shooting at close
ranges.
  Do not attempt to focus by means of the sharpness of the image visible in the view-
finder field. True focus is obtained by the split-image focusing zone.
  Because sighting and focusing is done through the picture-taking lens, there is absolutely

no parallax due to disparity of the optical axis; while interchangeable lenses of varying
focal length always give full coverage of the viewfinder field. The magnification of the
viewfinder image when using the standard lens  (f :48 mm) is x .26.
 When the shutter button is pressed, and the shutter mechanism is released, the view-
finder image is blacked out by the movement of the hinged mirror.  Recocking, by operat-
ing cocking lever (1), will return hinged mirror and aperture to viewing position.
  The markers visible along the right edge of the viewfinder frame are for exposure ad-
justment by means of the built-in exposure meter. Explanation of this function is given
below.
  AUTO'IIATIC APERTURE
  In order to provide the viewfinder the maximum brightness when sighting and focusing,
the aperture opens up fully (tll.9 in the case of the standard lens) when the cocking
lever is operated. When the shutter button is pressed, the aperture automatically closes
down to the previously adjusted fl  setting, and exposure of the film is effected at
this value.
  COUPLED EXPOSURE METER
  The built-in exposure meter of the MAMIYA PRISMAT is coupled to the shutterspeed

www.butkus.us

dial (a) and the aperture dial (5) by means
of a cursor (blue pointer) visible at the right
edge of the viewfinder field, which is brought
into alignment with the exposure meter
needle (slim opaque marker). Moving either
the shutterspeed dial (4) or the aperture
dial (5) will cause the cursor (transparent
blue pointer) to move. Deflection of the
exposure meter needle is caused by the in-
tensity of the light reflected by the subject,
impinging on the photocell through the
photocell window (8).  When the cursor is
in true alignment with the exposure meter
needle, the exposure controls (aperture and  shutterspeed) are properly set for correct
exposure of the film.
  However, when actually taking pictures, the filmspeed dial (7) must first be set at the
ASA number (speed rating) of the film in use.  Failure to make this adjustment will result

in incorrect coupling of the built-in exposure meter to the exposure controls.
  Shutterspeed and aperture settings are changed by turning the respective dials (4 and 5).
Shutterspeeds may be changed either before or after cocking. With aperture settings,
however, it is more convenient to adjust after the cocking lever (1) has been operated to
permit viewing and focusing.
  COCKING. AND SHUTTER OPERATION
 When the cocking lever (1) is swung through its stroke by means of the thumb, the
film is advanced one frame, and the shutter mechanism is cocked. The lever will spring
back if  it is released. It  is preferable, however, to ease it back into original position
gently.
  The cocking lever (1) remains locked, after cocking, until the shutter is released by
pressing the shutter button (2).
 When the MXV selector (10) is set at "Y",  the built-in self-timer (shutter action delay)
is brought into action. The shutter will operate approximately 10 seconds after the shutter
button is pressed. Moving MXV selector (10) to  " V " can be done either before or
after cocking.
  Caution 1. Operate cocking lever (1) or shutterspeed dial (a) only after shutter action

www.butkus.us
 has been completed. This caution applies particularly to B
 setting (bulb-shutter remains open for as long as shutter
 button is kept depressed) and to slow shutterspeeds (1 and
1 2 second).
  Caution 2. Do not operate cocking lever while built-in
self-timer (shutter operation r,r-ith MXV selector at ,,V")
is in action.
  Caution 3. When using neither self-timer nor synchro-
                                    ,,X".flash, keep MXV selector (10) at
  LENS CHANGE
  The MAMIYA PRISMAT is designed for use at will of
three types of lenses; the standard F 1.9,  f :4g mm; the
F 3.5, f :38 mm wide angle ; and the F 3.5,  f :100 mm
telephoto.
 When removing the standard lens from its mount, keep
depressed in direction of arro',r- the lens catch (11) with
the left thumb, grip with the right hand the lens barrel

where the depth of field scale (19) is engraved, and turn
                           lens barrel counterclockwise   until red dot comes into
                              alignment with red triangle  (shutterspeed index mark).
                       Then the lens barrel can be  lifted clear of the mount.
                                     (Fig. A, B and C)
                       To mount standard lens on body, match red dot on
                             lens barrel with red triangle on mount.  Push lens
                          catch (11) with  left thumb, then turn lens barrel
                                clockwise until it locks in position when the lens catch is
                                      released.
  Caution l.  When removing and replacing lens, always grip lens barrel at depth of field
scale (19) position and never by the focusing ring (3).
  Caution 2. When the lens is removed, either the hinged mirror or the shutter vanes
will be exposed. On no account touch these delicate parts.  If there is any speck of dust
on these parts, remove by squirts of air from a bulb syringe.
  Caution 3. After refitting lens on mount, always move aperture dial from f.ll.9 to  f 122
or vice versa to ensure proper coupling of iris diaphragm mechanism.

www.butkus.us

             FIIM TOADING

  Standard 3S-millimeter miniature film is accepted by
 the MAMIYA PRISMAT, monochrome or color, 20 or 86
exposures per roll.   Standard safety cartridges or the
special MAMIYA cassette for users of bulk or dark-
room loading film can be used. When loading camera,
however, avoid direct sunlight, work in the shade under
subdued light.
  1. When backlid catch (12) is pulled out, the backlid
is released.
  2. Swing backlid fully open, then pull out rewind
crank (13).  Place loaded safety cartridge or special
cassette, knob end down, in cartridge chamber (15).
Pull out a few inches of the film, and fit end in  slit
of take-up spool (17). Wind at least a turn on take-up
spool, seeing to it that the perforations engage sprocket

www.butkus.us
                                  teeth. Take up slack by turning rewind crank (13) in
                                     direction of arrow; then snap shut the backlid. (See
                                      Figs. 1, 2, 3, and 4).
                                  3.  Operate cocking lever (1) and release shutter by
                                 pressing shutter button (2).  Repeat two or  three
                          such blank shots until exposure counter (.14) moves
                            from triangle mark to numeral 1. You are now ready
                                            i;     for your first picture.
                                                     'i      4. Turn filmspeed dial (7) and set at ASA rating of
                                                  ii     the film in use. The rod dots indicate ASA 32 and 160.

                 COUPTED EXPOSURE METER
   1.  First, make sure that filmspeed (ASA) dial (7) is set at the ASA rating of the film
  in use.
   2.  Next, set shutterspeed dial ( ) at desired shutterspeed.
   3.  Sight subject through eyepiece. The slim dark marker (exposure meter needle) rvill
  indicate the brightness of the subject-matter.

www.butkus.us
  4. Turn aperture dial (5) so that the cursor (transparent blue marker) comes into
exact alignment with the exposure meter needle. The exposure controls (shutterspeed
and aperture) are now set to give correct exposure of the film.
  5. When alignment of the cursor and the meter needle cannot be obtained, that is to
say the cursor cannot be brought into overlap position even at either maximum or
minimum aperture size, re-set shutterspeed at slower or faster position then adjust aperture
dial (s)
  6.  Shutterspeed dial (4) must be set in click-stop position (at any one of the scale
graduations). Aperture may be at any point within the scale range since adjustment is
continuous, not in steps.
  7. The shutterspeed dial (a) may be used for adjustment of the cursor  if  desired. In
this case, however, the cursor will jump in steps, and fine adjustment by the aperture dial
(5) will be necessary. Also, excessively slow shutterspeed in combination with extremelv
small aperture may be obtained.
  Caution 1. When using the coupled exposure meter to obtain the correct exposure
settings, make sure that the photocell window (8) is not obstructed in any way. Otherwise
the meter needle indication will not be correct.

Caution 2.  If, with shutterspeed at 1 and with aperture fully open (f/1.9 with the
standard lens), the exposure meter needle remains at the low end of its range' beyond the
reach of the cursor, the subject is not bright enough to register properly on the film'
  Caution 3.  If, with shutterspeed at 500 (1i500 second) and with aperture at 22 (t122),
the exposure meter needle is deflected upward beyond the range of the cursor, the bright-
ness is such that overexposure of the film will be caused. In this case, a filter must be
used to reduce the intensity of the. light transmitted by the lens. However, tne main
subject itself may not be excessively bright, and the overexcitation of the exposure meter
may be due to extraneous light (such as direct sunlight on the photocell window). Make
sure that conditions are normal.
  Caution 4.  It is therefore advisable to measure the brightness of the subject at as close
a distance as is practicable, catching only the light reffected by the subject. With the
exposure determined in this way, the cursor and the meter needle not necessarily be in
alignment when actually shooting the subject from a greater distance.
  Caution 5. When taking pictures of subjects that cannot be approached, measure bright-
ness by training camera on foreground to eliminate much of the sky.
  Caution 6. Under reverse lighting conditions, or when subject is photographed against

www.butkus.us
the sky, be sure to measure brightness of the subject only; otherwise underexposure of
the subject will result, and a silhouette effect will be obtained.
  Caution 7. When a filter is in use, compensation is necessary. This can be readily
effected by means of the filmspeed dial (7).  If, for instance, with the filmspeed dial set at
200 for film of ASA 200 rating, a filter with absorption factor of. x2 is in use, simply shift
the filmspeed dial setting to 100 before matching cursor and exposure meter needle. If the
absorption factor of the filter is x4, shift filmspeed dial to 50.

                     CAMERA GRIP
  Supporting the weight of the camera on the palm of the left hand, the left thumb and
index finger are made to grip lightly the focusing ring (3). The right hand grips the right
side of the camera, with the ball of the right index fingertip resting lightly on the shutter
button (2), and the thumb on the cocking lever (1).
  Bring camera up to eye level, and a steady grip is achieved. (Fig. A)
 When adjusting exposure controls by means of the coupled exposure meter, merely
shift grip of left thumb and index finger to the aperture dial (5) or the shutterspeed
dial (a).

tr'?





                                    G)""","& * i                   *f
  When using camera in vertical position, first set exposure controls and focus in normal
position, then swing cocking lever side up, supporting weight of camera with the left
hand at the left side, now facing downward. Keep left elbow tight up against your body.
 (Fig. B)
                                                                                            use   If the cocking lever side is facing downward, support weight by right hand, and
right thumb to operate shutter button (2). Steady camera by means of the left thumb
and index finger gripping the focusing ring (3). Keep right elbow tight up against your
body. (Fig. C)
  These basic grips are used r,vith any of the interchangeable  lenses.

www.butkus.us

                          FOCUSING

 When the cocking lever is operated, and swung fully through its stroke, the film
is advanced, the shutter mechanism is cocked, and the viewfinder is activated with the
aperture fully open.
  While sighting the subject, turn focusing ring (3) so that the split-image of the subject
seen in the focusing zone at center of the viewfinder field becomes correctly aligned.
  1. For ease of judging correct alignment of the subject, choose clearcut vertical lines
such as poles, tree trunks, window frames, and nose and cheek lines.
  2- When taking vertical position pictures, first focus in normal horizontal position, then
turn camera on side for composing and shooting.
  3. Once the subject is in focus, the distance between camera and subject will be indi-
cated on the distance scale (18). The available depth of field (focusing tolerance) will be
shown on the adjacent depth of field scale (19). When it is necessary to check available
depth of field with higher precision, consuit the depth of field tables.
  4- When using infra-red film in conjunction with red filters, adjust focus in usual way,
then, noting the distance indicated on the distance scale, shift this reading to the index

mark  ,, R ".  This is necessary in order to compensate for the shift in focus due to the
shorter wavelength of infra-red rays.
DEPTH OF FIETD
  Depth of field is the term applied to focusing tolerance at a given distance. If  the
camera is focused on a certain subject at a distance of say 15 feet, there is available,
depending on the aperture setting, a certain leeway in front of and behind the subject in
which objects will register with adequate sharpness. This leeway is known as " depth of
field."
  The following are the attributes of depth of field:
  1. Depth of field varies with aperture size : smaller the aperture the greater the depth.
  2.  Depth of field varies with focused range : greater the distance the greater the depth.
  3. The shorter the focal length of the lens, the greater the depth of field.
  4.  Depth of field is greater behind the object in exact focus than in front.
  The depth of field of a given lens is determined by its focal length and its inherent
resolving power (expressed by size of circle of confusion). Depth of field tables are
 furnished to provide a more accurate guide than the depth of field scale on the camera.
  With proper awareness of depth of field, it is possible to obtain photographs with sharp

register of subjects at varying distances from the camera.
  For example, to obtain a picture of a subject 20 feet from the camera in front of
a building 40 feet distant, both in sharp register, the aperture setting should be at f.18, and
the focus (distance setting) should be at 15 feet. If, at the same aperture setting, the
camera is accurately focused on the subjects at 10 feet, background objects up to only
18.5 feet distant will register sharply
  Using this principle,  it  is possible to dispense with focusing for subjects more than
13 feet distant from the camera by pre-setting the focus at 30 feet on the distance scale
(18) and using aperture settings of fl9 or less (11, 16 and 22).

                    UNTOADING FILM
 When the specified number of exposures available on the film has been used up, stop
taking pictures, and return film into safety cartridge or special cassette.
  1. Press sprocket release button (20), It will remain depressed. Erect rewind crank (13)
and turn in direction of arrow to return film into safety cartridge (MAMIYA cassette).
  2. When end of film is reached, and the end becomes detached from the take-up
sprocket, this can be sensed by feel. Stop rewinding so that end of film is not wound

www.butkus.us

 into the safety cartridge. Open backlid, avoiding direct illumination, and remove cartridge
 (or cassette) by pulling out rewind crank (13). Depressed sprocket release button (20) will
 return to original position when the cocking lever is operated
   Caution l.   If after the specified number of exposures (sometimes before) the cocking
 lever jams part way through its stroke, do not force. Press sprocket release button (20),
and complete cocking lever stroke to permit it to return to original position.
  Caution 2.  If, when the cocking lever jams, force is applied, the end of the film may
become detached from the cartridge spool, making it  impossible to rewind the exposed
 film.    If  this happens, unloaC camera in complete darkness. Otherwise film will be
 spoiled.

                     SHUTTER OPERATION
  1. Shutter dial (a) and MXV selector (10) may be adjusted whether or not the cocking
lever has been operated.
  2- When using synchroflash, the MXV selector (10) is set at position M for class M
flashbulbs, and at position X for electronic flash (strobo) or class F flashbulbs. For normal
use, always keep MXV selector at position X.
