Mamiya RB67 Prism Finder User manual

By usingthis eye-levelfinderwith
         your Mamiya RB. you can view the
         su bject right side up and correctright
           to  left from a 30" angle With  its
      m a g n i f i c a t i o( n2 2 x ) , t h e b r i g h ti m a g e
          finder greatly easeseye-levelpicture
         taktng



       Mounting lo the Comero
            Mounting the eye-levelfinder is
          identicalto that of the focusinghood
         1   First, remove the focusing hood
            from your camera
         2  Slide the name plate on the front
               to the directionmarked by arrow
               1, then remove the  protection
            cover by pulling it as indicatedby
             arrow 2
         3   Slip two prongson the rearbottom
              into grooveson the camerabody
            Return the name plate firmly to
                                i t s o r i g i n a pl o s i t i o nw h i l e h o l d i n g
             the front of the finder

www.orphancameras.com

Eye-correcfion  lens
   The opticalsystem of the camera
finder rs designedfor easy, fatigue-
free vrewing for users wrth normal
visron Personswho do not wear glass-
es in spite of their nearsightednessor
farsrghtedness.or whose sight is not
sufficientlycorrectedby glasses,usu-
ally find  it  difficult to observe the
finder image Such personsmay find
this eye-correctionlens (an optional
accessory)a  boon  to  facilitating
p i c t u r et a k r n g
    Eighttypes of lensesare provrded
from *3  to -4  diopters(each diopter
 l s + 3 , + 2 . + 1 ,  0 5 , - 1 , - 2 ,   - 3 a n d
  4)
llounting   lhe  Eye-correc-
tion lens
   Remove the eye-cup from the
frnder Push the correctionlens into
the eye-pieceframe, and replacethe
eye-cupIn posrtron
