Page 1 · Read text
www.butkus.us
MIHANEA MULTI.DEDIEATED
FLASHtrUN
7@@GD
TNSTRUCTIONsView original page 1Page 4 · Read text
ATTACHMENT TO CAMERA (Fag.3t
The f lash unit has a "Hot Shoe" base and can
be attached directly to a camera having a flash
accessory "Hot Shoe" contact, which will
hold the flash unit and provide the electrical
connection between camera and flash when
the locking nut is tightened.
TCAUTION
When mounting the flash unit on or detaching
from the Camera always make sure the power is
OFF or the Camera may be damaged
www.butkus.us
Fis. 3
3View original page 4Page 6 · Read text
FLASH OPERATION-READY TEST (Fig. 5)
1) Turn the power switch "ON".
2l Alter approx 5 to 10 seconds the "READY"
light should light up, confirming your
flash unit is charged in readiness for flash
photography.
(The Test button, when depressed will fire
the flash gun confirming that it is
operational).
3) When flash is no longer required alurays turn
power switch "OFF".
Fig. 5
5View original page 6Page 9 · Read text
www.butkus.usAPERTURES AND DISTANCES FOR AUTO- 2l By sliding the bottom scale, set the switch to
MATIC OPERATION (Fis. 9) the focal length of camera lens (28, 35, 50
The flash unit has two automatic operation or 85mm).
settings designated by the colors red and blue. 3) Set switch (4) on the front of the flash body
The shooting distance depends on the zoom to the red or blue position.
position of the flash head. The blue setting is for 4l Set the aperture of the camera to the corres-
shooting at distances of up to 20 feet (6meters) ponding F stop indicated by the blue or red
at f/4 ASA 100/DlN21 at wide position. For arrows on the guide table. lf flash photos are
longer distances, use the red setting which allows then taken within the indicated distance
shooting up to 30 feet (9 meters) at f2.8 (ASA (corresponding to the red or blue lines above
100/DlN 21 at wide position). the meters/feet scale) correct exposures will
When using the zoom head your automatic be obtained in almost every situation.
operating distances can be increased. For infor- 5) When using bounce at longer range it is often
mation on this please see guide table P. 12). worthwhile to check the exposure by firing
the f lash gun using the Test button, if the 'Using the guide table: "Auto Check" light glows the exposure will
1) By sliding the top scale in the exposure table, be correct.
set the scale to the position corresponding to
the ASA/DlN rating of the film in the camera.
aView original page 9Page 12 · Read text
NOTES ON AUTOMATIC OPERATION
1) When shooting outdoors in day light, intense
illumination may cause the computer and
the auto check lamp to malfunction, in
such cases it may be advisable to use manual
setti ng.
2) After the Ready Light glows always wait for
a few seconds before making an exposure,
as sometimes the flash gun may not be fully
charged.
'{.
11View original page 12Page 16 · Read text
DEDICATED INSTRUCTION
To set the Select switch (2) to the right position
to use with your camera:-
Position "S" for cameras without dedicated
function
Position "O" tor Olympus cameras
Position "H" for Chinon 4 & 5 series cameras
Position "M" for Minolta cameras
Position "C" for Canon "A" series cameras
Position "P" tor Pentax cameras
When the Ready lamp goes "on", this dedicated
. flash will automatically set the shutter speed
of camera to 1/6O second or "x" synchro
setting and have indicating signal inside camera's
viewfinder.
15View original page 16Page 17 · Read text
w'
www.butkus.us
SPECIFICATION
Guide No. | 25 ASA 100 DIN 21 in meter (N 35mm position) 40 ASA 25 DIN 15 in feet (N 35mm position)
30 ASA 100 DIN 21 in meter (S 50mm position)
50 ASA 25 DIN 15 in feet (S 50mm position)
34 ASA 100 DIN 2f in meter (T 85mm position)
56 ASA 25 DIN 15 in feet (T 85mm position)
Angle of CoVerage: N 35mm position 60o x 45o
S 50mm position 46" x 34o
T 85mm position 32" x23o
1CiView original page 17From the M. Butkus archive. Original publisher and archive notices are retained.
