Ricoh KR-10 SE User manual

I

t
I    DESCRTPTTON OF PARTS          1. Film Rewind Knob/Back Cover Lock Release Knob
        2. Film Rewind Crank
        3. Film Speed Dial (ASA)/Exposure Compensation Dial
        4. Film Speed Lock Button
         5. Flash Ready Signal Contact
        6. Hot Shoe/Flash Contact
         7. Shutter Speed Index Line
        8. Shutter Speed Dial
         9. Automatic Exposure Lock Button
       10. Cable Release Socket
          1 l  Shutter Release Button
     12 Shutter "ON-OFF" Index Mark
       13. Film Advance Lever
            1 4. Exposure Counter
       15. Neck Strap Eyelet
           1 6. Lens Release Lever
           1 7. Lens Locator Node
         '18. Focusing Ring
       19. Distance Scale
      20. F-Stop Ring
        2 1. Sprocket Teeth
      22. Viewfinder Eyepiece
      23. Flash LED
        , 24. Film Rail
      25. Film Rewind Shaft
      26. Film Chamber
      27. Battery Compartment Cover
      28. Tripod Socket
      29. Winder Contacts
      30. Shutter Release Connection
      31. Film Rewind Release Button
      32. Winder Coupler


                                                         -l-
                                www.butkus.us

33. Positioning Hole
34. Film Take-up spool
35. Back Cover
36. Film Pressure Plate
37. Microprism-image Band
38. Split-image Spot
39 Exposure Meter Needle
 40. Shutter Speed Indicator
41. Viewfinder Eyepiece Cop





We are most gratified that you have selected the KR- 1 OSE which we
are sure will give you many delightfull years of picture-taking
pleasure. The KR-1OSE is a 35 mm fully automatic electronically
controlled exposure system (aperture-priority) SLR camera which
assures you of superb optics and outstanding mechanical perfor-
mance and reliability and which will justify your choice for years to
come.

Before Using Your KR-1OSE
Please read this instruction booklet carefully and familiarize yourself
with the equipment and its features thoroughly. Your pleasure in us-
ing your KR-1OSE will be greater if you know your camera properly.

BATTERY LOADING
The built-in through-the-lens CdS exposure metering system of your
KR-1OSE operates on power activated by two 1.5V LR44 alkaline
bateries, which are supplied together with your cameera.
  1. Remove Battery Compartment Cover l27l bV unscrewing it
    counterclockwise with a coin (Fig. 1).
 2. Place the two batteries into the compartment with the plus @
    side down, as illustrated in the battery holder of Battery Com-
    partment Cover l27l (Fig 2). Make sure that the batteries are
     correctly placed.  lf incorrectly placed, Exposure Meter Needle
    (39) in the viewfinder will not move at all.
 3. Replace Battery Compartment Cover l27l by screwing it
    clockwise until it stops but do not force.

Tips for Better Results
 *  lf the shutter release button is pressed when there are no
     batteries or they are worn out, the mirror will stay up and the
     shutter cannot be released. To put the mirror back to its proper
     position, turn the shutter speed dial to "X" or "8", and be sure to
     insert new batteries immediately.  lf you wish to take pictures
    without using batteries, use "X" (t/90 sec.) or "8".
 *  Before loading, wipe off the surfaces of the batteries with a clean
   and dry cloth to ensure they are free of fingerprints or stains.
 * When your camera is not used for a long period, remove the
     batteries and keep them in a cool. dry place.
 * The batteries will last for about half a year in normal use.
 * The batteries may explode  if disposed of in fire.





                         www.butkus.us

'    '-FILM LOADING
Your KR-1OSE is designed to accept any standard 35 mm color or
black and white film roll in cartridge. (12,20,24 or 36 exposures).
  1. First of all, press Shutter Release Button  ('l 1) to see that the
    shutter has been released. (Refer to "METER/SHUTTER ON-
   OFF CONTROL")
 2. Pull uo Film Rewind Knob (1)until Back Cover (35)snaps open
     (Fig. 3). Then, pull it out all the way to allow for insertion of the
    film cartridge.
 3. Swing open Back Cover (35)and place a film cartridge into Film
   Chamber (26) (Fig. 4).
 4. Push down Film Rewind Knob (1)to itsoriginal position byturn-
     ing Film Rewind Crank (2) clockwise or counterclockwise so that
    Film Rewrnd Shaft (25) engages the film cartridge and that the
     film cartridge is seated in place (Fig. 5).
 5. Draw the film leader across the camera back and insert it into
    one of the slits of Film Take-up Spool (34) (Fig. 6). To bring the
      slit into a convenient position, rotate Film Take-up spool (34) in-
    the direction of arrow with your finger.
 6. Rotate Film Take-up Spool (34) by advancing Film Advance
    Lever (13) to take up any slack in the film and check to see that
     the film tip is firmly hooked onto Film Take-up Spool (34) (Fig. 7)
    and that sprocket holes on the film are fully engaged on Sprocket
    Teeth (21) (Fig. 8).
  7. Close and press Back Cover (35) firmly until it snaps shut.
  8. Advance Film Advance Lever (13) two or three times, after
    depressing Shutter Release Button (11) each time, until the
    number "1" is opposite the index line in Exposure Counter (14)
      (Fig. 9), because the first portions of the film can not be used for
     picture taking ds they have already been exposed to light and
    two or three blank exposures should be made before taking your
      first picture. Now it is ready for your first picture.

Tips for Better Results
   * Always load your camera in the shade or in a poorly-lit place,
     never in direct sunlight or other bright light.
   * As you advance the Film Advance Lever (13). the Film Rewind
     Knob (1) will simultaneously rotate counterclockwise indicating
      that the film is advancing properly.
  * When making blank exposures with Shutter Speed Dial (8)set at
     "AUTO", set F-Stop Ring (20) to the smailest f-stop (the targest
      lens opening) so that you can make next blank exposure quickly,
     otherwise a slower shutter speed will be result which could be an
     annoyance.

 SETTING FILM SPEED
 Each type of film, color or black and white, has its own sensitivity to
 light. This sensitivity is assigned by a numericalvalue described as an
 ASA rating (U.S.A. Standard)or a DIN rating (Europe and most other
 countries). In most cases, both ASA and DIN ratings are imprinted
 on the film package, as well as the data sheet packed with the film
 and the film cartridge  itself. The higher the film speed rating, the
 more sensitive the film is to light; that is, less light is required for a
 proper exposure. The film speed, therefore, is an important element
 in insuring that the through-the-lens metering system of your camera
 determines the correct shutter speed and f-stop combinations for a
'given lighting situation.
 1. Depress Film Speed Lock Button (4) (Fig. 10) and rotate Film
    Speed Dial (3) until the ASA number of your film is exactly op-
      posite the index line and click stops. For example,  if the film is
   ASA 1OO, make the correct setting at "100" (Fig. 11)
 2. Take your finger off Fitm Speed Lock Buttbn (4) to tock the film
     speed setting in the camera.




                          www.butkus.us

Tips for Better Results
 * Each time a film with a new film speed ratrng is loaded in your
    camera, the film speed must be set to assure accurately exposed
    photographs.
 * The scale reoresents the relation between ASA and DIN numbers
     is illustrated on the inside of Back Cover (35) (Fig. 12).

METER/SH UTTER "ON-OFF" CONTROL
Film Advance Lever (13) controls shutter release "LOCK-UNLOCK"
to protect your camera from accidental shutter release when not tak-
ing pictures and Shutter Release Button (1 1)controls exposure meter
"ON-OFF" to avoid unnecessary depletion of the batteries.
1. When Film Advance Lever (13) is moved to "ON" position (Fig.
    13). Shutter Release Button (11) is unlocked.
2. When Shutter Release Button (1 1) is pressed half way down, the
     electric circuit is switched on and Exposure Meter Needle (39) in
    the viewfinder starts to move.

Tips for Better Results
 * Whenever picture-taking is completed, be sure to move Film Ad-
    vance Lever (13) to "OFF" position (Fig. 14).
 * To prevent unnecessary consumption of the batteries, do not
    press Shutter Release Button (11) often.
 * The Film Advance Lever can be set at two angles in click stage
    positions. Choose the one suitable for your own shooting style.

SETTING SHUTTER SPEED DIAL
 The shutter controls the length of time the light is allowed to strike
 the film. The speed at which the shutter opens and closes is measu-
 red by the numbers on Shutter Speed Dial (8). In automatic exposure
 operation, correct shutter speed is set automatically.




 I Simply turn Shutter Speed Dial (8) until the desired shutter speed
    is set opposite Shutter Speed Index Line (7).
O        ... "AUTO" stands for AUTOMATTC. Setting the diat at
        "AUTO" makes the camera ready for automatic exposure
            control.
@     The numbers 10O0, 50O etc. to 2 stand for 1/1OOO sec..
         1/5OO sec., etc. to 1/2 sec,
@     The numbers 1,2,4, stand for 1 sec.,2 sec., and 4 sec.
O       This button locks the dial at "AUTO" setting. When you
     .    move the dial off "AUTO", press the button and rotate the
             dial.
O      "X" stands for mechanical shutter for the speed of 1/90
         sec. This setting is used when the batteries have not suf-
           ficient power or taking picture without batteries. Flash
         photography is also possible at this setting.
@.......... "B" stands for Bulb. The "B" setting is used for long night
         exposure using street lights or electric signs as a light
          source, or under poor lighting conditions when flash can
          not be used. When set at "8", the shutter will remain open
       as long as Shutter Release Button (1.|) is depressed
          (preferably by a cable release).

                        www.butkus.us

' : "Tips for Better Results
 * Do not set Shutter Speed Dial (8) between marked speeds, but at
   a click stop in accordance with indicated speeds only.
 *  Shutter Speed Dial (8) does not revolve between "AUTO" and
       ,,8,,.
 * When Shutter Speed Dial (8) is set at "8" or "X", set the desired
    f-stop and expose manually because metering with the built-in
    exposure meter is not possible.
 * When making extremely long time exposure at "8" setting,
    remove the batteries to avoid unnecessary consumption of the
     batteries.

SETTING APERTURE
The lens opening determines the amount of light entering the lens
and exposing the film. The smaller the f-stop $/2.O, f/2.8 etc.l, the
wider the lens opening and the greater the amount of light entering
the lens. The larger the f-stop $/16,f/11 etc.), the smaller the lens
opening and the smaller the amount of light entering the lens. As the
fens opening is moved lrom t/16 to f/11, the amount of light entering
the    f ens is doubled. As the lens opening  is moved lrom l/2.O to l/2.8,
the amount of entering light is cut in half (Fig 15).
 I Rotate F-Stop Ring (20) until the desired f-stop is opposite the
   aperture index line (Fig. 16). Click stops are provided to prevent
   accidental movement from the setting made.

Tips for Better Results
  *   lf necessary, you may set F-Stop Ring (20) between two f-stops.




                            -8-

CORRECT EXPOSURE
Automatic Exposure
Your KR-1OSE has a built-in through-the-lens full aperture CdS ex-
posure meter coupled to aperture-priority automatic exposure control
system which selects and sets correct shutter speedautomatically for
correct exposure.

 Set the camera to "AUTO"
  1. Turn Shutter Speed Dial (8) until the "AUTO" is set opposite
    Shutter Speed Index Line (7) (Fig. 17). Shutter Speed Indrcator
    (40) in the viewfinder indicates "A", showing that the camera  is
    set for automatic exposure control (Fig. 18).

 Preselect the aperture
 2 Preselect the desired aperture by rotating F-Stop Ring (20). For
    preselecting the aperture, refer to the following rough guide
   when using ASA 1OO film.
        Outdoors in bright sunlight        .., I/8.O -  t/16
        Cloudy weather or in shade       f/2.8 -  t/5'6
       lndoors                                    ..- f/1'4 -  l/4'O

 Exposure checking
  3. After moving Film Advance Lever (13) to "ON" position, press
     Shutter Release Button (11) lightly half way down until the Ex-
    posure Meter Needle (39) begins to move. The Exposure Meter
    Needle (39) in the viewfinder indicates the shutter speed you will
    be shooting at. ["1OOO" is 1/1000 sec., "125" is 1/125 sec.,
    "4" is 1 /4 sec., "1" is one full second and "  i, " is 2 seconds.l.  lf
    the needle goes above " 10O0" (Fig. 19), close down the aperture
      until the needle moves below "1O00".  lf the needle goes below
    "8.X." (Fig.2O), open up the aperture until the needle moves
    above "B.X.".

                       www.butkus.us

Tips for Better Results
  * At slow speeds(below 1/30 sec.), use a tripod or other firm sup-
    port to prevent camera movement and blurred pictures. In
     shooting with a telephoto lens, be careful to minimize the camera
    shake especially. When using telephoto lenses, a good rule of
    thumb is "use a shutter speed faster than 1/focal length of the
    lens". For example. with a 135 mm lens. use a shutter speed
     faster than 1/125 sec. Otherwise, a tripod is suggested.
 * Coupling range of the exposure control for ASA 100 film is from
    1/2 sec. at f/2 to 1/lOOO sec at I/11 (EV3 -   171.
 * The shutter speed is automatically determined at any speed
    within the range of approx. 8 sec. to 1/1000 sec., according to
    the lighting conditions of your subject.

Manual Exposure
Manual exposure setting is used when taking flash photography or
when you wish to preselect the shutter speed.
     'l . Press Automatic Exposure Lock Button (9) and move Shutter
    Speed Dial (8) off "AUTO" (Fig. 21). Then, set the desired
     shutter speed opposite Shutter Speed Index Line (7) by rotating
    Shutter Speed Dial (8). Shutter Speed Indicator (4O)in the view-
     finder indicates the shutter speed you just set.
 2. Move Film Advance Lever (13) to "ON" position.
 3. Hold your camera, look at your subject through the Viewfinder
    Eyepiece Q2l and press Shutter Release Button (11) lightly half
   way down.
 4. While keep pressing Shutter Release Button (1 1)half way down,
    rotate F-Stop Rrng (2O) and align Exposure Meter Needle (39)
    with Shutter Speed Indicator (40) (Fig 22l,. lf Exposure Meter
    Needle (39) goes above Shutter Speed Indicator (40), this means
     . "overexposure"; select a faster shutter speed or a smaller lens
    opening. On the contrary, if the needle goes below Shutter
   Speed Indicator (40). this means "underexposure"; choose a
    slower shutter speed or a larger lens opening.
                      -10-

EXPOSURE COMPENSATION DIAL
         The dial is used when exposure compensation (intentional over_ or
           under-exposure)  is necessary in AUToMATIc EXposuRE ooeratron.
            In unusual lighting conditions, the desired effect or the correcr ex-
           posure will not be obtained in the final picture and exposure compen-
           sation is necessary.
I            I  Lift up the outer ring of Exposure Compensation  Dial (3) and rotate
                  rt until the index line on the ring is opposite the corresponding I          number (+2. + 1.                                    and click stops (Fig. 23).                            -1, _21
       When the light is behind tho subjects
            Set the dial at *1 or *2.    (Jor{Ku6. e5
          Spot-lighted subjects and dark backgrounds
            Set the dial at -1 or -2.
          Tips for Better Results
          * when exposure compensation is unnecessary, be sure to set Ex-
             posure Compensation Dial (3) at ,,0,,.
          * Do not set Exposure Compensation Dial (3) between marked
             numbers, but at a click stop in accordance with indicated
            numbers only.

      VIEWING AND FOCUSING
         Since you are viewing through the lens, there is no parallax
            problem.....
        what you are viewing in the viewfinder wiil exactry appear in your
          picture. This enables you to determine the exact composition of yourt
          subject before pressing Shutter Release Button (1.l). Even when you
         shoot close-ups, there is no danger of accidentaily cutting off a por-t
          tion of your subject. To assure the sharpest possible pictures, vour
        KR-10 has a three way focusing screen with diagonar sprit-image
         spot (38). Microprism-image Band (37) and Fresner fierd, and you
        can select three way focusing according to your subject.
                                www.butkus.us-  lt -

1. Look into Viewfinder Eyepiece l22l to compose your picture'
 2. Split-image Focusing.....is  helpful for the subiect with either ver-
    tical or horizontal lines.
    Rotate Focusing Ring (18) until the split image in Split-image
   Spot (38) forms a single image. when it is out of focus, your
    subiect is split into two parts (Fig 24)
 3. Microprism Focusing.....is good for the subiect which lacks clear
    vertical or horizontal lines.
    Rotate Focusing Ring (18) until the image in Microprism-image
   Band (37) appears sharP (Frg 24)
 4. You can also focus with any part of the area surrounding
    Microprism-image Band (37). This is most useful when taking
    pictures with ultra telephoto lenses or in close-up photography
    with bellows unit, macro lenses or extension rings because the
    other focusing aids may darken appreciably'

UNLOADING FILM
After the last picture on the roll of film has been taken. rewind the
film and unload your camera.
  I' Press Film Rewind Release Button (31) (Fig 25)'
 2. Lift up Film Rewind crank (2) and turn it clockwise until Film
    Rewind Release Button (31 ) stops revolving and you feel the film
    tension released (Fig. 26) This indicates that the film has been
    completely rewound into the cartridge'
  3. Open Back cover (35) by pulling up Film Rewind Knob (1).
  4. Remove the film cartridge and have the film processed as soon
    as possible.

Tips for Better Results
  * Always unload your camera in the shade or in a poorly-lit place,
    never in direct sunlight or other bright light'
  * when you reach the end of the roll film, Film Advance Lever (13)
      will tighten and refuse to advance lf this happens' do not ad-
                  _12_

vance Film Advance Lever (r 3) by force for "just one more shot".
      otherwise the film will be torn out of the cartridge.
   *  Film Rewind Release Button (31)will remain in place once it is
      pressed. and return automaticaily to its originar position when
      Film Advance Lever (13) is advanced.
 TAKING FLASH PICTURES
 You can use a frash at night or in a dimry  rit room as weil as for
 supprementary lighting in outdoor photography. The camera and
 electronic flash will be fully synchronized with the shutter speed at
 "B","X" and 4 sec. to 1/125 sec. Since proper flash exposure may
 not be obtained by automatic exposure setting, always override
 Shutter Speed Dial (8) from "AUTO,' settrng.
 The RlcoH XR Speedrite 24o is avairabre excrusively for use with the
 RICOH KR- 1 OSE.
 How to Use the RTCOH XR Speedlite 24O
  1. Attach XR Speedtite 24O to the KR_1OSE.
  2. Turn on the power source switch on the flash unit.
  3. When the ftash unit is fuily charged, the FLASH LED (23)on the
    frame of the view-finder eye-piece wiil turn red indicating  it is
    ready for use.
  4. When the shutter speed on the camera is set to ,,AUTO,,,  rt rs
     automatically synchronized at   'l /90 sec. This avoids the trouble
    of having to set the correct speed yourself.
  5. with ASA 1oo firm, the F-stop shourd be set at s.6, and the frash
     unit will automatically control the amount of light to give the cor-
     rect exposure.
Tips For Better Results
 * Do not use other makes of frash units that have a speciar signal
    pin exclusively for their cameras. as this will result in incorrect
    exposure or may even damage the circuitry.
                                                               ,,AUTO,, * The XR speedlite 24o has a range of synchronization  of
    "8", "X", and from 4 sec. to 1/125 sec.
                      www.butkus.us

ln Cases where You Do not Use tre XR Speedlite 24O
  Usc a flash unrt with a built-in hot shoe contact only because the
   camera  is not equipped with flash termrnal for a flash unit wrth con-
   necttng coro.
   Exposure for Flash PhotograPhY
   The exposure is determined by the guide number of the electronic
   f|ashunit'Theguidenumberrepersentsarelationshipbetweenthe
   |ightoutprtofthef|ashandthespeedofthefi|m.Guidenumbersfor
    electronic flash units are found in the technical specifications. Using
   theguidenumber,youcandeterminethecorrectf-stopforagiven
    flash situation using the following formula:
      F-stop  :  Guide number +  Flash-to-subject distance
   Forexamp|e,ifyourf|ashunithasaguidenumberofl6(m)or52.8
     (ft.) for the type of film you are using' and your subject is 2 meters
    (6.6 ft.) from the flash unit as indicated on Distance Scale (19) after
    focusing, divide 16 (52.8) by 2 (6.6}. The answer is 8; set F-Stop
   Ring (lg) to 8 (f/8).

   Tips for Better Results
     *   lf you are using an auto electronic flash unit with power ratio
         control, follow the instruction sheets packed with the flash unit
     * Most electronic flash units have a built-in dial or exposure table
       whichenab|esyoutoquick|ycomputef.stopsbasedonf|ash-to-
1       subiect distances.

  VIEWFINDER EYEPIECE CAP
   when shooting with the self-timer or cable release where you will not
   be viewing through Viewfinder Eyepiece l22l at the time the ex-
    posure is made, viewfinder eyepiece cap should be used to prevent
    stray light from entering through the eyepiece and affecting the
    automaltc exposure system. (Fig 27)'

CHANGING  LENSES
 To mount the lens on the camera
         'l . Mount the lens by linrng up the red dot on the lens mount with
     the matching dot on the camera mount (Fig.28).
  2. Grasp the lens firmly around the lens barrel and turn  it clockwrse
      until it clicks into place. (Fig. 29)
 To remove the lens from the camera
        'l . Grasp the lens firmly around the lens barrel in one hand.
 2 Wrth the other hand, hold camera body and press Lens Release
     Lever (16) and turn the lens counterclockwise until  it stops (Fig.
     3O). The lens now can be removed.
 You can also change lenses without looking even in the dark by
 means of Lens Locator Node (17). Line up Lens Locator Node (17)
 with Lens Release Lever (16) anO turn the lens clockwrse for moun-
 ting the lens. For removing the lens, press Lens Release Lever ('l 6)
 and turn the lens counterclockwise until Lens Locator Node (1 7) and
 Lens Release Lever (1 6) lrne uo.
 Tips for Better Results B"r{ka|, v5
  * Whenever a lens is mounted on the camera. make sure that the
     lens is perfectly mounted. and clicks into positron.
  * Do not touch any of the internal parts or permlt dust or dirt to
     enter the camera body when removing or attaching lenses.
  * Protect the inside of the camera by putting on the body cap
    whenever the camera is carried or kept with the lens removed.

DEPTH OF FIELD
When you focus on a specific subject, an area in front of and behind
the subject will appear acceptably sharp in your picture. This area of
acceptable sharpness is called "Depth of Field". The depth of field is
determined by the f-stop you select and the distance from the in-
focus subject to the film plane. As you get closer to your subject, or

                     www.butkus.us

as you open your lens (for example, lrom f/16 to t/2 81, the depth of
field becomes shallower. By stopping the lens down (for example,
trom f/2.8 to  f /16!', the depth of field becomes deeper.
Tips for Bettor Results
 *  Infrared radiation varies with the degree of infrared light rays in
    the atmosphere.
 * For exposure, follow the instruction sheets which are packed
    with the film, and expose manually because metering with the
     built-in exposure meter is not possible.

INTERCHANGEABLE LENSES AND ACCESSORIES
A wide range of XR RIKENON interchangeable  lenses including ex-
tremely wide angle lenses. telephoto lenses. zoom lenses and various
accessories are available to enable you to expand the pleasure of your
picture-takinS. XR RIKENON interchangeable lenses and accessories
are made of selected high quality materials under strict quality control
to assure you of high performance and full satisfaction. Select XR
RIKENON interchangeable  lenses and accessories that will meet your
needs.
Since the camera is designed to accept any lens with the "K" type
bayonet mount, your KR-1OSE affords you the opportunity to select
any interchangeable  lens or accessory of the "K" type bayonet mount
available on the market.
RICOH XR WINDER.l:
The RICOH XR WINDER-1 can be used with the KR-IOSE. By
operating the shutter release button on the winder, it can be used for
rapid sequence photography at approximate 2 frames per second. (at
shutter speed of 1/ 125 sec.) By just setting the selection switch you
may choose frame-by-frame shots or rapid sequence shots according
to your needs. You can for instance capture the rapid movement in
sports. or the fleeting facial expressions that make your picture-taking
a more enjoyable exprience.
                              - 16 -

PROPER CARE OF YOUR CAMERA
 * Always carry your camera with its carrying case and neck strap.
 * Use the lens cap to protect the lens when not taking pictures.
 *  Protect your camera from dust. dirt, water, rain, dampness, salt
     air and rough handling.
 * Never expose your camera to excessively high or low tempera-
     tures for an extended period of time. In extremely hot climates,
   do not leave your camera inside closed automobiles during the
    daytime or in direct sunlight. In extremely cold climates, expose
    your camera to the outer air only when in use..... When using,
    expose your camera gradually to the outer air to prevent the lens
    from clouding.
      lf exposed to an extremely cold climate, the exposure meter
    batteries may fail to operate properly. Keep your camera inside
    your clothing until taking a picture.
 * Never touch the surfaces of the lens, metal focal plane shutter
     curtain, reflex mirror. etc. with your fingers.
 * To clean the lens, gently wipe it in a circular motion with a lens
    cleaning paper or a soft, clean and lintless cloth.
 * Do not wipe the camera body with chemicals, such as benzine,
    thinner. etc., use only soft cloth or cotton swab sprinkled
   LIGHTLY with alcohol on the camera body. Do not use them on
    the lens because it can affect coating.
 * When your camera is not in use for an extended period of time,
    put the lens cap, remove the batteries, place your camera in its
    carrying case together with silica gel or other desiccant and store
      it in a dry and cool place.
    Never store your camera in places where the temperatures are
    excessively high or low.
 * Do not attempt to disassemble or repair your camera yourself.  lf
    service is necessary, get in touch with your dealer or authorized
   Ricoh service station.
 * Do not leave your camera near the magnetic objects like radio,
    television set etc,

                      www.butkus.us

MAJOR SPECIFICATIONS OF KR-IOSE
Gamera Type:
   35 mm aperture-priority AE (automatic exposure) SLR with
    electronic metal focal plane shutter
Film Size and Capacity:
    35 mm perforated film in 12.20,24 or 36 exposures
Film Format:
   24x36mm
Standard Lenses:
   55 mm RICONAR f/2.2, 4 groups 4 elements
     Filter size: 52 mm screw-in type
Lens Mount:
    "K" type bayonet with 65'rotating angle
Shutter:
     Vertically moving Copal CCS-E electronically controlled metal
     focal plane shutter
    Automatic electronic shutter: continuously variable speeds from
    LT (approx. 8 sec ) to 1/1OOO sec.
    Manual electronic shutter: stepped speed from 4 to 1/1 O0O sec
                                        "B" and "X"   '  Manual mechanical shutter without batterles:
    (1/90 sec.)
Viewfinder:
     Fixed eye-level pentaprism
     Shutter speeds, "A" (automatic), "8" (bulb), "X" (1/90 sec.), Ex-
    posure meter needle, Shutter speed indicator
    Viewing magnification 0.83X
     Field of vi;w covers 93o/o of actual picture area
     Flash ready lamp (LED)
Focusing:
    Diagonal split-image spot in microprism band surrounded by
     Fresnel field

Exposure Meter:
    Three CdS photocefls TTL full open metering for center-weighted
    average light reading coupled to aperture-priority automatic ex-
    posure system
Exposure Coupling Range:
   EV3 .- 17 (ASA 1OO film with 5O mm f/1.4 tens)
Film Speed Range:
   ASA 12 - 3200 (DtN 12 -  36l'
Exposure Meter Power Supply:
   Two 1.5V silver-oxide batteries (G13, MS76, 576) duration
    about a year.
   Two 1.5V alkaline batteries (LR-44) duration about half a year.
  Two 1.5V mercury batteries (H-C, EPX675, PX675) duration
   about half a year.
Flash Synchronization:
   X synchronization  for electronic flash unit at "8"  , "X" (1/90 sec.)
   and 4 sec. to 1/125 sec.                     FUfkczS.uSAutomatic Flash Control:
    With Ricoh XR Speedlite 24O, set shutter speed dial at Auto, and
       it will set shutter speed 1/90 sec. automatically,
    Manually set the aperture ring to the same aperture set on flash.
Film Loading:
   M ulti-slit easy loading
Film Wind:
    Single stroke film advance lever with 135. winding angle (40o
     PlaY)
    Automatic winding possible by mounting Ricoh XR Winder-1.
Film Rewind:
    Film rewind crank by pressing film rewind button on base of
    camera
Exposure Counter:
     Additive, automatic resetting



                      www.butkus.us

Other Features:
    Plus/minus 2-stop exposure compensation dial l+2' +1' O'
     - 1. -21   ASA/DlN conversion label (on back of back coverl
    Automatic exposure lock button
    Hot shoe
    Shutter release lock (with film advance lever)
    Meter on/off switch (with shutter release button)
   ASA dial lock
    Cable release socket
    Tripod socket
Dimensions:
    140 (width) x 91 (height) x 50 (depth) mm (body only)
Weight:
   545 g (body only)
I Specifications are subject to change without notice.
