Samoca 35 User manual

www.butkus.us





                                                      I

         FEATURES
FILN{ SIZE   :      36 pictures of 24 x 36mm on 35mm
                           f ilm
LENS:           Fully corrected anastigmat coated
           EZUMAR F:50mm l-:3.5
SHUTTER:       Vario type
                 1125, L150, 1i100 and ttBtt action
                     Built-in flash synchronized
FOCUSING:       Helicoid Focusing
                with depth of field scale and fixed
                  focus marks
FILM WINDING: Auto stop and auto film indicator

                    [1]

Fie. 3





O Film Winding Knob  @ Focusing Lever
@ Shutter Release Button @ Lens Opening Ring
@ Distance Scale     @ Shutter Speed Dial
@ View Finder     @ Film Pressure Plate
@ Accessory Clip    @ Film Chamber
@ Shutter CockingButton @ Sprocket Gear
@ Rewinding Knob   @ Lock Lever
@ Film Counter Dial     @) Tripod Socket
@ Depth of Field Scale  @ Film Cartridge
@ Flash Terminal    @ Take-up Spool
             (31

HOW TO USE         www.butkus.us
I. LOADING FILM
   Turn Lock Lever (77) on bottom of Camera from
                    Camera Back by pulling it to-  'L"  to trO'l and open
  wards bottom.
   SAMOCA CAMERA can be loaded with 35mm
  Daylight Loading Cartridges of any make commercially
   available.
    Pull end of film about 3 f inches and slide it into
  the slot of Take-up Spool.
     Lift Fihn Pressure Plate 04) and insert both Film
  Cartridge and Take-up Spool, facing emulsion side of
  film towards Lens, and turn Film Winding Knob (1)
                                       until film is tight
                             and Sprocket Gear
                                                    fl6) fits the holes
                                of film.
                              Put back film-
                                      pressure plate, slide
                                 in and fix Camera
                               Back and turn Lock
                                Lever from ilOtl
                                    to t/Lt/.
                                 To advance part
                               of film exposed
    www.butkus.us                        during loading, push

               (41

Shutter Cocking Button ot release Auto-Stop of Film
  Winding Knob and turn Knob (1) towards arrow until
    it stops, two times.
    Turn Film Counter Dial (8) to set //O 7 at Red Dot.
   The Camera is ready for use.
2, HOW TO TAKE PICTURES

                        Judge distance be-
                      tween Camera and
                       Object and  set
                                 Distance Scale by means
                                of focusing Lever  (11).
                             Set Iris   Diaphragm
                            Scale by turing Lens
                         Opening Ring 02) to
                                  desired Stop.
                        Set Shutter Speed
                          Dial (13) on front of
  Camera at desired speed with Red Dot.
    Only 3 Steps needed to tal<e picture.
    (1) Set Shutter Cocking Button.
    (2) Wind up Film Winding Knob until it stops.
    (3) Push down Shutter Release Button.
   .Fihn Counter Dial (8) always indicates Film
  Number automatically and prevents Double Exposures.
   When using Flash Unit, fix end of electric cord to
                        i5l

www.butkus.us
                                  Terminal  (10)
                                   then Flash
                              Lamp will work
                                          simultaneously
                                    with shutter.



   When using Wire  Release, screw it into Shutter
   Release Button (2).
3. UNLOADING  FILM
   When you have
   taken all exposures,
  film must be re-
  wound into original
   Cartridge by turning
  Rewinding Knob(f)
  clockwise before
   unloading.
   To release the
  Sprocket Gear (lg)
  Qhutter Cockirrg
  Button must be
  pushed down during
.  rewinding.
                       t6j

4, FIXED FOCUS
   When taking snap shots, it  is convenient to take
  at Fixed Focus without setting Distance Scale each
   time.
    Set Distance Scale at 24 ft (Red Figure) and Lens
  Opening at 8 (Red Figure), then any objects between
  11 ft. and Inf. will be in sharp focus.

              FIELD SCALE5. DEPTH OF
   When reducing lens opening, depth of field increases
  both in forward and in backward direction from the
   distance on which lens is focused- The depth of field '  for any given lens opening and distance setting can
  be correctly ascertained from the depth of field scale-
   It is represented by the distance settings opposite the
  two diaphragm setting figures on right and left side
   of the diaphragm setting mark.
