Ultrablitz Cornet L flash User manual

l. Ultroblitz C0RNEI I is olwoys with you





Owing to its smoll ond convenient shope ond its
low weight, the CORNET L moy be eosily instolled
for floshing ond corrying. lf you hide your equip-
ment in your pocket you con do the floshing with the
qORNET L like o mogicion, os only the comero ond
the high performonce flosh lomp ore visible.
Whether the equipment is corried in o lody's hond
bog, in o suit-cose, in the pocket of your iocket or
overcoot or whether you cqrry it with o shoulder
sling strop under or over your clothing the CORNET L
will never bother you ond will be olwoys with you.

www.butkus.us

2. Technicol doto
Guide numbers  t          92...105 Blqck-white 17o DIN (40 ASA)                               46... 53 Colour    18" DIN (50ASA)
Electricol output:        opprox. 40 Ws
Colour temperoture:      opprox.5600o K.
Number of floshes:      per occumulotor chorge
                         opprox.40...50
Time between floshes:     9...12 sec. occumulotor operotion
                            l4 sec. moins operotion
Flosh      durotion:                  1                             /2000 sec.                                            fi*lJfui 'uj                                   560                        opprox.Light      ongle:
Moins voltoges:            olternoting, current 1.l0...125 ond 220V,
                            40...60 cycles, built-in chorger
Bottery:                     3.6 V nickel-codmium occumulotors
                          (without mointenonce)
Comping focilities:       coble for chorging from cor-bottery 6 ond 12 V
                           (speciol ottochment)
Weight'                opprox.940 groms (2.1 lb) complete with flosh lomp
Dimensions:               qpprox. 41/z x31/s x 1 tl  inches

r
I;                                       www.butkus.us
          Push the flqsh lomp with the spring-looded  foot
              into the shoe on your comero or





          mount it on the universol brqcket (osk your deoler)
             on'd screw this to your comero.




           Plug the synchronising leod into the comero ond
            set the synchronising lever to "X". Set the shutter
          to obout l/1ee sec. (with focol plone shutters see
          comero hondbook).
                                                                5

For corrying, disconnect the flosh heod
                                               ./ from the comero ond fix the lomp on
                                               I   the cose by meons of the rubber cords.
                                           Slide the operotion switch to positibn
                                                                          " otF'  .





    lmportont nole: Switch off the equipment ofter toking o flosh picture, to ovoid
    unnecessory droin on the occumulotor. To leove  it switched on needlessly for
6  one minute is equivolent to the loss of one flosh.

www.butkus.us

4. Moins operolion


The CORNET L moy only be used from olter-
noting current. Before connecting up to the
moin,s it must be switched to the correct
voltoge. The switch for this is the slofted
socket pin for the mqins connector on the
si,de of the equipment. By meons of either
o screwdriver or o coin the slot must be set
to the correct voltoge (22Q or with 1.|0....l25 V
to 1'17). For the connection to the moins
ony normql connector with o flqt iron socket
will do.

Switching on is occomplishe,d by slid,ing the operotion switch so thqt the
mork "-"   is visible. In this position the built-in occum,ulotor will chorge ot
the some time. The equipment is swilched off by sliding ihe operotion.switch
to the middle position "OFF".

5. Chorging the ocrumulotor
                                       After connecting the CORNET L to the
                                        moins, set the operotion switch lo " nt".
                             Then the occumulotor will begin to
                                    chorge. No further operotion  is neces-
                                        sory. During chorging the signol lomp
                                       will light up ot the flosh heod. The
                                            built-in nickel-codmium occumulotor is
                                 gos-proof ond does not need ony
                                    m'ointenonce. A sure sign for  the
                                  chorge stote of the occumulotor  is the
                                 time between floshes thot is the time
                        on bottery operotion, which posses
                                      b.etween floshing ond lighting up of the
                                        srgnql lomp.
                                          9...12sec. fully chorged
                                                l8 sec. holf dischorged
                                          30 sec. completely dischorged
When the time between floshes reqches 30 sec. then the qccumulotor must be
re-chorged. Chorging time will then be opprox. l4 hrs. At 18 sec. between
floshes o chorging time of 7 hrs. will suffice. No domoge will occur to the
occumulotor if it will be unchorqed even durinq extended periods or if  it will
be.overchorged occosionolly. Its time of seriice is very'long, it moy be
rechorged opprox. 400...500 times.

www.butkus.us

             Should the equipment be left switched on ot bottery operotion for severol
               hours, by mistoke, the occumulotor will be fully dischorged ond the vibrqtor
                will not work. The nickel-codmium occumulotor will not be destroyed [y
             such oction but it will require up to 60 hours to fully chorge ogoin. After
               further 2 or 3 dischorges of normol flosh working ond normol chorging of
               l4 hours eoch time, ihe occumulotorwill ogoin reoch rts normol power output.
           The CoRNET L con olso be chorged from o cor-bqttery 6 or j2V with the1              cor-chorging coble ovoiloble os o speciol ottochment.
 l



              6. Reoctivoting lhe flosh copocitor
                    lf the equipment is not used for severol weeks, it should be connected to
              the mqins for 20 to 30 minutes before floshing it (switch to moins operotion).
            The equipment will then reoch its full floshing power.

7. Aperlure Computer ond
      Guide Number





     Unlike doylight ond constont orti-
       ficiol light sources by which the re-
     gulotion of the film exposure is pos-
     sible by operture ond exposure
     time, with the very short electronic
     flqsh this regulotion con only be
    done by the operture.
     For the simple computotion of the necessory operture there is the operture
     computer on the flosh lomp. For block ond white films, set the block qrrow
      to the sensitivity volue of the film being used (e. g.17o DIN), for colour films
     use the red orrow. The corresponding operture (e.g.5,6) con be reod off from
'10 the rotqting disc opposite the requir,ed distonce (e.g. 16 ft).

www.butkus.us

Guide Number
Should the ronge of the computer be unsufficient,  i. e. the film sensitivity folls
below the volues given, then from the guide number (see poge 13) the cor,
 responding operture con be computed with the following formulo:
Guide number  :  Aperture, e. g. for 320 ASA film _:5,6280
 Distqnce                                           50
                                                                                                                                      a
whereby distonce :  distonce from the lomp to ihe subiect in feet.                                                    $c,lFus'u>
The guide number is dependent upon the light output of the CORNET L
ond the film sensitivity. lt is qlso influenced by the light of the subiect to be
photogrophed, size ond lightness of the room ond the kind of development.
 It con only be token,therefore os o guide.
Theguide numbers ore given for medium sized rooms with light wolls.When
toking pictures in the open, in lorge holls orwhere the distonce from reflecting
surfoces is lorge, open the operture 1...2 stops further thon computed or
obtoine'd from the computer.
For distonces smoller thon 8 feet choose olso o lorger operture, e. g. of 3 feet'l  stop lorger.

www.butkus.us

10. UITRAB1ITZ Service
In spite of the smoll size the Ultroblitz CORNET L is relioble ond of o high
performonce on'd does not need ony mointenonce. The CORNET L is the most'
up-to-dote model, mode on modern equipment, ond hos been most core-
fully tested.
lf you ore dissotisfied with the performonce of your Ultroblitz CORNET L
equipment of ony time, pleose turn to the deoler from whom you hove
bought it or turn to the represeniotives of our compony in your country.
The ULTRABLITZ WORLD SERVTCE wilt be glod to help ond odvise you,
wherever you ore.
Pleose send the complete equipment for servicing ond indicote type ond
seriol number of equipment together with detoiled informotion obout oll
troubles you experienced with the equipment. Experience hos shown thqt
this is necessory for proper servicing your ULTRABLITZ.

   convenienf speciol equipmenf to complefe your coRNEI [,
                                Car-charging cable KA ISIlIz
                                                                                     t5
