Manika BOOKLET Product booklet

Directionsfor use of the
        f

                                   G"s




Feinmechonik
Fronkf urt om Moin   .

1) Opticol viewfinder-bqck
       2) Opticol viewfi nder-fronf
       3) Threod for coble-releose          ,
       4) Releose knob
       5) Frome-finder
       6) Ring for sefting lhe exposure times
      .   7) Ring for selting the sfops (diophrogm)
       8) Holding support
       9) Grip to disengoge the lozy tongs
     10) Quick-chonge lens mounl
     11) Eyeletsfor shoulder strop
      12)' Lever for lensioning the Compur shuller
     13) Stopper
     14) Tripod bush
\r    15) Focusingknob
     16) Knob for setting M ond X
     17) Eyepiece of ronge-finder
     18) Sighf for frqme-finder
     19) Mounting piece for flosh-equipment
     20) Scolefor Wide-ongle Ortho r 6.817.3
     21) Scole for Anticomors 10 cm.
     22) Scole for Anlicomors 10 cm. when the focoleplone
        otfochment is used
     23) Opiicol viewfinder bock wiih porollox compensolion
     24) Lock for plote holders
     25) Sockets for flosh cord

,
                  !t
         , t       r-
#f
     To open the Mokino
     Hold the comero by ifs long side with fhe left hond ond drow
      ihe front forwqrd with thumb ond middle finger of the right
     hqnd until the slruts snop in oudibly. Mqke sure thot bofh the
      struts reolly click in so lhot lhe front is porollel fo lhe bqck.

    The Mokino hos snop-in posifions,one for lhe shorler ond the
     olher for the longer exlension. The short extension must be
     used when the Ropid Wide-ongle-Orlhor  is employed, while
     the longer extension fits the Anticomor ond lhe Tele Mokinor.
    Moke sure you hove lhe correct exlension for lhe lens you use.
    The rongefinder is designed for the longer exfension ond does
      nol work  wifh the wide-ongle lens ond the Tele-Mokinor.

     To close fhe comero
          lf comero hos been sef for neor objects, lurn indicotor bock to
       infinity. Wifh the thumb qnd middle finger of righi hond press
     the ribbed metol grips (9) on eqch side ond push front bqck;
       firsf close Newton finder on the fronl ond olso lhe profecling
     cover with fhe lens on the bock.

    How  lo hold fhe Mokino
    Spon holding grlp (8) on comero front with righl horid (thumb
     behind, index finger on the releose knob, the olher fingers in
      front) while ihe left hond holds comero with ihumb ond index
      finger by the focusing knob. At the some fime Press comerc
      slightly ogoinsl foreheod. By fhis meons lhe comero con eosily
     be held quite sfeody ond is olwoys reody for oction.                                              '1
     Focusing
    On the left hond side of cdmero front is the focusing screw (15)   \
     by which  fhe crossed slruls ore moved       the distonce
                                                    .with
   . 1


                           www.butkus.us

r'4r  1.,
     I

        indicolor over ihe scole (21) on right side of comero front. This
        scole gives lhe dislonce in melers orfeet. The focusing knob is
       on lhe left side. As the comero is held wifh fhe right hond the
       focusing knob con be lurned even jusf before lhe exposure (fhe
         right index finger on the releose knob) ond the disfoncesetfing
      moy be chonged ot the losl inslonl (on imporlont feofure when
        children ot ploy or onimols hove fo be photogrophed).
       Belween the ,,infinify" mork ond the 30 feet mork o specioldot
        indicqles the ,,hyperfocol distonce" (neordistonce dot) upon                                                 I
       which the lens (of opertures betweenf:5.6 ond f:11) should be
       focused lo give the greorest depih-of-field possible.All objects
       from obout holf the hyperfocol distonceto infinity will be shorp,
        lhof is, especiollyin fhe middleground which is imporlont for
       mosl of the pictu res.
      The coupled  ronge-finder      ft.//os'z       )-
      The ronge-finder of the Ploubel Mqkino  is bosed upon the
       "coincidenceprinciple", i. e. it conioins 2 mirrors, one rigid
      ond one od jusloble,lhe lqtter of which is moved by f he focusing
       device of the comero. When looking fhrough the eye-pieceofft"
       fhe ronge-finderyou will see o reclongulor imoge of yellowish
       colour qnd o smoll, round picfure of white colour. By turning
        lhe focusing screw (on left side of the comerofront) the lozy
       long struls of the cqmerq odjust simulfoneouslythe front prote
      ond fhe movoble mirror, so thof the circulor white picture
      moves over fhe yellowish one; when both pictures coincide
       the piclure is correctly focused ond obsolutely shorp.
       For using lhe ronge-fin'der,firsl pull out ihe Mokino until both
        slruls snop in posirion. Now  pull out the nickled lelescopic
       eye-piece of the ronge-finder ond look through  it. When the
      cqmero is sef for,.infinify", you will see fhoi both picfures of


                                                   \

lhe ronge-finder coincide for  distont objects, whereos neor
objects will show 2 different picfures, side by side. By lurning
lhe focusing screw until both picfures coincide, you will get
lhe correcf distqnce ond definition. Pleose olwoys keep in
mind fhot the "sine quo non" of oll ronge-findersis fo look'
stroight through lhe eye-piece,nof obliquely (sidewoys).

For objects in motion the ronge-finder moy olso be used os o
direct finder (though f he odgle of view is only obout '1/3 of the
whole ongle of the picture shown on lhe plote or film), os in
most coses instonloneousphotos require only the moin object
focused. Firsf set the Compur shutler lo  f he exposure.

The ronge-finder of fhe Mokino is coupled only fo the Anti-
comqrs 1:2.9flO cm. ond 1:4.2110cm., but nof to the Tele-
Mokinor 1 :4.8 ond the Wid'e-ongle-Orthor 1:6.8.lf is possible,
however, lo use the ronge-finder for these lenses olso by
meosuringlhe disfonceond seffing lhe disloncefound by using
lhe melre- or footscolelhof is ploced ot the front of the Mokino
below fhe opiicol viewfinder. See porficulors given wifh fhe
vorious lensesond supplementorylenses.

lmporlonl!  We wish to emphosizethot oll coupled ronge-
finders ore inslruments of lhe highest precision ond lherefore
sensitiveto rough hondling. The comerq should be corefully
hondled ond ony hord knocks should be ovoided. The nicker-
ploted holding screws should under no circumsloncesbe
louched, unscrewed or odjusted!  lf the ronge-finder or   f he
coupling should be domoged the comero musl be returned io
lhe foctory.

The-Compur-Shullers   of lhe Mokino
The Mokino cqmeros ll, llS ond  lll ore equipped wifh the

6


                       www.butkus.us

Compur   I shutter. The Mokino lf lR hos the new Ropid Com-
 pur  I shutter.

 The setting of the exposure lime required is done by rototing
 the wide, brig hf rofory ring (6) su rround ing the lens.To sim pl ify
 fhe selting il hos o setting mork on lop os well os below. The
 volues given ore froctions of o second (e.g.Z5:1125 second)
 ond fhe exposure fime indicoted is obtoined when lhe locoling
 mqrk with the figure coincideswith the whife or blqck dol on
 the front-ponel. When set to 1/200 or 11400q morked resisfonce
 will be felf ond o liitle more force hqs ro be used ro turn lhe
 ring. This is quite in order os on odditionolspring istensioned
 for fhese speeds.
 Prior fo exposure Compur shutters hove lo be cocked by
 pressing down the lever (12) on the right side of the comero
fronl unlil il snops in. After cocking this lever (12) runs home
outomolicolly info its originol position.
For long lime exposures os well os for fhe exominolion of lhe
imoge on fhe ground gloss screen, the shufter must be sel lo
"T". When fhe releose lever (4) or the coble releose is pressed
home the shulfer opens ond sloys open unlil o second squeeze
of lever (4) closesit. The setting ,,B" for shorl time exposures
is different in thot fhe shutter opens when the rereqselever (4)
is pressedond closesf he moment lhe pressureceoses.When set
lo "T"  or "B" the shutfer musl not be cocked or  it will be
domoged!
Deloyed oction releose (selftimer) for Mokino   ll ond llS.
Set shuller lo fhe desired speed from 1 second lo 1/100 seconc.
It is importonl fo note thot the selflimer connol be used wilhout
domoge io the shuller when the loffer is set to 1i200, T or B.

Push lever 12 down, now press wifh the finger on knob V ond
then pressdown with lever 12o secondtime. Then trigger4 is
presseddown.either wif h f he finger or the coble releose.After
                 '10-12                    seconds the shutter will be releosedo deloy of obout
oulomoticolly. This deloy ollows fhe photogropher to oppeor
in the picfure himself.
Mokina  lll ond  lll R
The shutters of these lwo models hove no deloyed ocfion
releose! Olherwise the instructions for use of the Compur
Shutter hold true for lhese comeros loo.
Wifh  one  imporlont   exceplion  concerning  only  fhe
M q k i n o   l l l R :
The new Ropid Compur shutler hos to be cocked even when
set to "T" ond "B"!
Stop-Adjuslmenf.    - An  imporlont feoture: The Compur
shuller set lo 1 -11400second con be'opened withoul rotofing
lhe exposure-lime selfing ring in cose you wish lo hove thot
fomous 'rlostlook" of the focusingscreen:
Cock the shutler in the normol woy, buf hold lhe cocking lever
(12) dowi thus preventing it from sliding home, press bullon A
ond releoselever 12. This lever now remqins hqlf cocked. Press
releose lever 4 ond the shufier will open ond will sioy so.
To closethe shufter,presslever 12 down ogoin until it snopsin.
The butfon A will then spring bock ond lever 12 slides bock.
Prior lo the qcluol exposure the shutter hos, of course, lo be
cocked ogoin.
The shutler releose lever (4) is ploced in the righthond top
corner of ihe front ponel. The shutter is releosed by o slow,
steody pressure with the righl index finger. To ovoid comero

 I


                       www.butkus.us

shoke if is vitolly necessqryto squeeze lhe releose lever ond
 nol to press ii with o jerk.
The coble releose s hou ld be screwed into f he th reqded ferru le
 (3) ot the side of the releose lever (4).  lt  is used for time
exposuresmoinly.

The viewfinder
The Mokino is equippedwif h o direct vision opficol viewfinder,
 ond, furlhermore,  with  o  frome:finder (which  is olwoys
 relioble ond the most convenienl of oll). Both viewfinders ore
eye-level finders which oulomolicolly eliminoies ony lolerol
porollox.           b4Krl        (
Wifhin the rectongulor while"    lens of the opticol viewfinder the
size 4,5 x6 cm. (the full size divided inlo lwo holves) is cleorly
morked to simplity operotions, os is ihe imoge field of the iele-
lens olso. The bold lines in ihe drowing below exploin the
morkings. Seeolso poge 12.
  -t-l   -tt-

         A n t i c o m q r F : 1 0 c m .             T e l e F : 1 9 c m .
               4,516 cm.                     619cm.

Porollox  compensolion:  The eyepiece of fhe oplicol view-
finder is qlloched to o revolving secfor, which when elevqted
lowers fhe visor lens. At the end of the second is q dislonce
scole thot ollows correci focusing of the imogefield - especiolly
of close-ups.The revolving secfor ensures the compensolion
for the verlicol porollox.
Cosselles: The filmpock, rollfilm, ond plote-holders must be

inserted into fhe ground-gloss screen frome in the usuol woy
(prior fo this remove the nickel-ploted holding bor (24)!)
Ploubel Plote holders
Above the plush lining of the holder is o smoll lever which
operoleso vernier insidethe holder; iurn this lever up to the
right then pui the plofe into the holder toking it by the thumb
ond middlefinger of the left hond ond pressingdown the upper
edge of the plofe wif h the firsl finger, lhen furn f he lever down
lo ils closed posifion when fhe plote will be firmly fixed.
lf is necessory,of course, to press home fhe plote sufficienily.
ll must be pushed underneoth fhe supporting flonge ond nol
ogoinsl ils edges. Olherwise the plote-holder moy be domoged
or the plote crock.
The plofe-holder should be pulled out of lhe comerq by press-
ing the holder upword with the thumb of the left hond while
pulling it ouf with fhe righi hond.
Rof I fil m holders qre ovoi loble for the sizes6 x 9 cm. (21| a x31| a
in.);6 X6cm.(21laX21lain.)or24x36 mm. As usuolthe120spool
gives eighf negotives21lax31lain., eleven to twelve negotives
21l"x21lain. ond 16 negofives4.5x6 cm. (131ax21/nin.). The
74x36 mm. film holder is used with the normol miniolure film
corfridge for 36 exposures.Corefully study the insfruclions for
use of roll film holders.
Filmpocks:  The single film sheefs in filmpocks ore never
complelely flot like o gloss ploie. The distonce of fhe vorious
sheelsfrom lhe front of the pock differs g reolly with the vorious
mokes,ond in somefilmpocksthe singlesheetscurve oulwords,
in olhers inwords.
To ensure o sufficient definition lhe lens should be stopped
down io qt leosl 1 :5.6 ond smoller.

1 0


                       www.butkus.us

\

 Filmpocks must be hondled wifh the ulmosf core, only the
norrow  sides should be louched. Pressureon the bock or the
sofety sheet of the front will cquse,light to penetrole the pock
 before il is inserfed info ifs holder. Filmpock holders should
never be looded in sunshine,olwoys in the shodow.
The comero should not be opened when the shutter of fhe
dorkslide is pulled oui. Although fhe. Mqkinq  is fifted wifh
efficient oir ducfs, sucfion of the bellows is unovoidqble ond
mokes the film curve when lhe dork-slideis ooen.
The tripod  plote should be used when exposures hove to be
mode from o.tripod. The comero should be fixed to the ploie
with bofh ifs tripod bushes.The comero con then be screwed
to the tripod in horizonlol or verlicol posifion by meons of fhe
tripod bushesin the lripod plofe.

the OpticalOutftt
In f heMokino with ropid-chonge-mounl the lominoe of the
Compur shulfer ore behind fhe lens.

The lens is o complele unif in o precisionropid-chonge-mount.
The insertion or removol of fhe lens is done by o shorf roiotion
fo the left or the righi by gripping lhe lens mount ot the wide
milled edge iusl obove the fronl plofe. Do nof use force when
screwing in the lens! The ropid-chonge-rnouniensureslhe lens
hoving olwoys its correct position mechonicolly os well os
opticoll.y.ll does not mofler wether the sfop-numbersengroved
on lhe bqrrel ore in o differenl ploce from fhot before the lost
removol. Eoch lens hos ils own iris-diophrogm which con be
set to the stop-number by rotoling the ring (7) until fhe notch
coincideswith the slop required.

                                                                1t

The Anticomor    | 22.9llO cm. is on ideol lensfor sponloneous
work, especiollyfor picforiol work  in londscope ond portroit
photogrophy. Where o g rod uotion of su btile g rey lones, o soft
definition ond o cerloin "ploslicily"  is required this lens is
u nsurpossed.

The Anticomor   lz4.2ll|Gnr,  is o lens yielaing the highest
possible definition ond contrqsl ond  is the objective for the                  II
phofogropher of every-doy, tosk, news, mochines, orchilec-
furol deloils ond reproductions. lt  is ihe lens of fhe press-photogropher ond ihe troveller.                                   IIJ

The Tele-Mokinor  124.8,f:19 cm. (71lain.)
To mork the differenl  imoge  oreos covered by the Tele-
lens the white lens of the opf icol viewfinder shows the eng rov-
ing mentionedon pcge 9 under "Viewfinder". The chonging
snd lhe removol of the Tele-Mokinor S does nof differ from
thqt of the Anticomor. On lhe fronl-ponel of the'Mokino you
will find q red triongle, ond onother red mork is on the dio-
phrogmring of theTele-Mokinor.In orderlo enoblethe photo-
gropher to reod the stop-numbers from obove  it is recom-
mended thot the lwo red morkings on ring ond fronf-ponel
should coincide when fhe Tele-Mokinor is inserled.However,
should ii be screwed in differently,no horm will be done. The
                                                                                                       ITele.Mokinor os well os the Anticomor hove their own  iris-
diophrogm thot con be sel in the usuol woy. On iop of the lens                                        III
borrel, siop numbers ore engroved, ond obove them ore
ploced the dislonces in mefres or  feet. These two scoles                 T
togelher form  o  convenient depth-of-field-ring giving  the
correct deplh of field for every operlure. The Tele-Mqkinor S
employs lhe some coich spring os the Anlicomor.  ll is semi-
outomolicolly coupled to the ronge-finder, which meons lhot

1 2


                        www.butkus.us

ihe distonce is meosured with the ronge-finder ond lhen reod
off from f he Anticomor-scole.The focusing device of the comero
'remoins         unoltered, but the distonce meosured is set on fhe
Tele-Mokinor, which hos ils own disfonce sefting in its helicol
mount. For instonce: The subject is 9 feet owoy from lhe
comero. Meosuring with the ronge-finder resulls in the Anii-
comqr scole showing o disfonce of 9 feel. Now  the Tele
Mokinor: 1:4.8119cm. by virfue of its helicol mount is olso sel
to 9 feel, withoul  oltering  the  distonce  setfing  of fhe
cqmero.
The Ropid Wide-ongle-Orlhor   l:5.8,  f :7.3 cm. (23lain.)
Owing lo its short focol length o speciol cofch spring for the
loiy tongs of the comero is necessqry(20). The Ropid Wide-
ongle-Orthor hos its own iris-diophrogm ond musf be inler-
chonged like the other ropid chonge-lens.
The correcl imoge oreo  is found either by focusing on ihe
groundglossscreen or by using o smoll slip-on cop with lens
for fhe oplicol viewfinder. This cop is slipped on lhe viewfinder
in such o woy  f hot the lens of the cop poinls toword the subject
to be photogrophed. The Ropid Wide-ongle-Orthor  is nof
coupled lo the ronge-finder, but the lotter con be used by
meosuring lhe correct distonce befween subject ond comero.
Then lhe lozy longs ore mqde to engoge the cotch spring
provided for fhe wide-ongle lens ond lhe dislonce meosured
ihen tronsferred fo fhe helicol mounl's distonce setting. ln fhis
                                         'usingwoy good, ropid work cqn be done withouf      the focusing
screen.
Supplementarylenseifor close-u?s
The supplemenfory lensesshorfen the focol length ond, olso,
ihe dislonce belween comero ond objecl. This results in o

                                                                                                                                         l 3

mognificofionof lhe imoge scole, so fhese lensesore mainly
employed for fhe foking of smoll objects, for moking repro-
ducfions of prints ond pictures ond for photogrophing smoll
objecfs in their noturol sizes. The focusing is done wilh the
micromeler focusing drive of the Mokino ofter the distance
belween comero ond objecf hos been estqblished.When the
Tele-Mokinor is employedtogether wifh supplementorylenses
lhe focusing mounf of fhis lens con olso be used. The sfop-
numbers of the originol lenses(Anticomor, wide-ongle lens,
Tele-Mokinor) con be employed wifhout qllerofion, os the
equivolentfocol lengthsof fhe vqrious lens-combinofionswill
olwoys be resel lo the originol focus lenglh when close-ups
qre mode.

When supplementory lenses qre used it is odvisqble to stop
down consideroblylo ensure o good definition of the edges.
F o r f h e c o m b i n o l i o n1 - 7 o n d 1 1 , o b o u t f : 8 s h o u l d b e c h o s e n ,
while for the olher combinotionsfhe lens should be sfopped
down lo obout f :11 or  f :'16 (seefoble).

All our supplemenlory lenses hove o threqd for screw-in
filters so thot the combinotion lens ond supplementory lens
plus filter is olwoys possible.

With  lens T1.5  (especiolly suifoble for  flowers,  still  life,
portroifs) photogrophs con be mode ol o dislonce.of obout
65 cm. (2ft2") when the Anticomor is employed. The distonce
will be obout 115 cm. (46 in.) when lhe Tele-Mokinor is used
insfeod.When loking porlroits with Anticomor ond T1.5  it
musf be borne in mind thot the distqnce is rqfher short ond
dislortions connot be ovoided. Portroils in profile or semi-
profile will be beller thon fronfol picfures.

t 4


                       www.butkus.us

The lens DIN  con be used for o distonce of obout 45 cm.
(1611,,in.)
The lens RO.l  is for photogrophing smoll objects in lheir
noturol sizes. lt is not recommended thot the Tele-Mokinqr
should be used for fhis purpose ond the lens R0.1 does nof fit
the Mokinor therefore.
The mounls of the supplemenlorylensesT1.5 ond DIN for the
Mokino hove lwo ihreods in order to fit the oufer-threods of
fhe Anficomor ond the Wide-ongle-Orthoros well os the inner
lhreod of the Tele-Mokinc,r1:4.9, f :19 cm. The lens R0.1 con
be screwed only info lhe inner lhreqds of the Anficomor ond
the Wide-ong le-Orthor.
olaubelftlters
ln order to obloin o sotisfoclory representotion of colour in
terms of grey lones o good filter is indispensoble.We recom-
mend the exclusive use of our Ploubel filters for which floiness
ond porollelismis guoronteed.They ore mode of Jenq speciol
glosssloinedin fhe mossond ore in threoded mounfs.Screwing
the filters on lhe lens mount is the sofesl woy of ensuring o
correct opticol fitling with the leost Ioss of definifion.
Wifh our Ploubelfilters(seethetobleon poge17) inslontoneous
exposures ore oflen possible on occounf of the high speed of
the Anlicomor. With  the "stronger"  fillers lime exposures
should be mode ond if is usefullo slop down lhe lens to f:11
or f :16 fo obfoin o sufficientdepfh of field.
For  our  Mokino  with  ropid-chonge-mount    fillers  in o
speciolmount ore ovoiloblewhich ollow lheir employmentfor
oll our ropid-chonge-lenses.The inner threqd fits the ouler-
lhreod of the Anficomor ond Wide-ongle-Orthor,while fhe

                                                       1 7

ouler ihreod fits lhe inner ihreod of the Tele-Mokinar 1:4.8,
f : 1 9 c m .
1un shabe(lenshooD
The oll-metol sun shode with ifs cylindricol tube (deodblock
inside) prolecls fhe lens from reflecfionson the gloss surfoces.
 lf con be screwed on lhe lens either by ifs ouler or inner ihreod.
The Ploubel sunshodeollows fhe inserlion of Ploubel filiers,
supplementory lensesond Duto disks without the removol of
the shode from the lens. Pressingdovyn the lofch on fhe lube
ond hinging off the ring exposes on inner threod in the
fostening ring of the sunshode inlo which fhe filter or supple-
menlory lens con be screwed. The tube is ihen swung bock
ond the combinofion is reody for use.
Inslruclions  for using  f he detochoble focolplone  shulter
unit wifh the Ploubel Mqkino comero.
The focol-ploneshutter unit is slid into the roils on f he cqmero
bock in ploce of lhe usuol dork slide. On  its own bock qre
provided o secondset of roils, into which ihe dork slide,film-
pock odopler, rollfilm odopler or ground-glossscreencon be
fitted in the usuol woy.
Owing to the thicknessof the shuller lhe extension of the bel-
lows hos to be oltered to reslore the correct distonce between
the lens ond the film plone. A speciolcotch spring con be suppl-
ied by fhe foctory fo serve this purpose. However, lhe focql
plone shutterond the Wide-ongle-Orlhor connot be employed        ,A
togefher on occount of lhe lwo cofch springs thot con, of course,
noi be used simulloneously.
Focusingis done by the speciol scole provided when fhe focol-
plone shutteris in use.This is usuollyplocedover the fop of the

1 8


                      www.butkus.us

focusing scqle for fhe Anticomor lens. In lhose comeros lhol
 hove not been designed for use wilh ihe Wide-ongle-Orthor
 lens, it will be found ot fhe moving end of fhe lozy-fongs
focusing scole. The distonce meter should not be used wifh ihe
focol-plone shuller unif, though  it moy be used to reod the
distonce of o subjecf on the normol Anticomor focusing scole,
ond the mounl lhen ollered lo reod this sqme disfonceon the
speciol scole provided. The lozy-tongs musl then be moved
 into the neorer posifion before exposure.
The ollerotion of fhe shutler speed is eosily orronged by the
ploin knob. The lolter is pulled out genfly from the comero ond
turned to indicqte the desired speed. The knob is lhen releosed,
core being foken thqt the peg on its under side engoges cor-
reclly in the oppropriqfe hole below it. The shuller is releosed
by o brief pressure on lhe profruding butfon.
When usinglhe focol-ploneshuller unif, il is nofurolly essentiol
to be sure thot the Compur shulter of the Mokino is sel to ,,T"
ond open.     IJ 1;               t  )"
Flosh mechonism
The flosh mechonism consislsof three different ports:
1) Rotory knob 16 ond floshconfocts25 on the front plote of
   fhe comero
2) Slide 19 to foke the floshgunond
3) the floshgun (poge 21).
The octuql floshgun (pqge 21) consistsof :
       A  Reflector
       B Socket for flosh bulb
      C Sockets for two extension floshes
      D Boftery tube fo toke 3 U2 cells
       E Support for clomping device

                                                       1 9

F Press bullon for shutler releose vio
           eleclro-mognet
      G Cord with ihree-point plug
      .    H Lock nuf ot lower end of bottery tube
                 I  Strop lug.

There qre lwo different kinds of floshlight:
o) wiih consumoblefloshbulbs.- The Mokino hos o buili-in
   electro-mognet which ensures the synchronous opening of
   the shutler ond firing of the bulbs up to 11400second.All
  ffoshbulbswith o deloy of 16to 19 millisecondscon be fired
  when the knob 16 on lhe front ploie is sel to "M".The eleclro-
  mognef works only when the shulter is cocked properly! -
   Floshbulbsto use: G. E. ond Mozdo No. 5, 11,27; Sylvonio
  Press25, 40, 50; PhilipsPf 14,25,38, 60.

b) with eleclronicflosh (strobe- or speedlomp).
  Modern speedlompswork wif houf deloy!The knob 16 hos,
   therefore, be sel to "X".

Consumoble floshbulbs withoul  dbloy con olso be fired with
setling "X"'ond  1/25 sec. Floshbulbsto use: Philips PFS,
G. E. Speed Midget.

How  lo ofloch  the floshgun  lo lhe comero.

Push the floshgun directly over the slide 19, hinge down
clomping lever E1 ond fosfen il thoroughly. Connecl plug G
(poge 21) with  sockels 25. The  elecfricol releose of the
synchronisedshutler is done by pressing button F.
Thefloshguncqn be usedseporotelyfrom lhe comero if required
in which cose only the flosh-cord is connecfedlo lhe comero.

20


                      www.butkus.us

I mporlonl  recommendqf  ions :

  1) Prior to firing the flosh the shulter musf be cocked.
  2) Keep oll elecfricol contocts scrupulously cleon ond dry.
  3) Use fresh U2 botteriesonly, speciolflosh boiieriei with ot
    leost q currenl of 3 omps ore besf.
 4) Tesf botteries with  1/400 second os lhis exposure time
    requires fhe highest omount of currenl. lf one single pres-
    . sure on button F sufficeslo releose the shulter the bolleries
    ore in working order.
 5) The floshgun should be clomped firmly  lo the comero
    olherwise fhe electric connectionsmoy nol be secure. The
    clomping screw should be firmly tightened.
 6) Keep the cops of the floshbulbs dry olherwise they will
    corrode ihe contocts in the sockefs. To ensure q cleon
    metollic surfoce insert bulb in socket ond rolste  it q few
    limes lo ond fro.
 7) The sockei B fits bulbs with ES-cops.When bulbs with
   A.S.C.C.-cops musl be used on odopter (Order No. BE
    1/13)should be employed.
 8) To  protecl the lozy-tong mechonism from domoge the
   Mokinq musf be held firmly by the front plofe when the
   floshgun is mounled or dismounled!
 9) When using floshbulbs moke sure to odhere to the instruc-
    lions for use wilh regord to guide-numbers, deloy ond
   generol operolion.
10) For floshbulbs with q high currenf consumplion or for the
    firing of more thon 2 floshbulbs simultoneouslyemploy
   4 botleries ond use exiensionfube (order No. BE 1120)for
    botfery - conloiner.
n


                      www.butkus.us
