Page 2 · Read text
I{
                                                                                                                                                                                                                                        iilt'l
                                                                                                                                                                                                      lr


   Your Minolta SR-T 303 is designed and built to give
you greater speed and ease of operation and handling.
   Both F-number and shutter speed set are visible in the
viewf inder. A new-type "micro-split"   f inder screen aids
rapid, accurate focusing. Besides the recognized advan-
tages of  full-aperture, through-the-lens metering, this
camera features the exclusive Minolta CLC ("Contrast
Light Compensator") system   f or most satisf actory
exposure  in virtually  all lighting situations.
   In addition to  this better exposure-metering  and
viewing system, the Minolta SR-T 303 has features that
make  it handle easier and more responsively.
   Mu ltiple exposu re capab ility and a direct-contact "hot
shoe" are among the other advanced features of this new
camera.
   Before using your SR-T 303 for the first time, read
this manual carefully all the way through - or at least allthe sections needed to cover your own photographic
requirements. In this way, you can take good pictures and
begin to realize the full potential of your Minolta right
from the start.
View original page 2
Page 3 · Read text
www.butkus.us



 CONTENTS
 NAMESOFPARTS               ......2          Lens aperture controls
 MAJOR FEATURES                     .... 4         depth of field                    ........25
SPECIFTCAT|ONS                ......  5         Depth-of -f ield table of MC Rokkor
                                       50mm F1.4and F1.7 tens (in feet) .......27
 PR EPARATIONS BE FORE TAKING PICTURES        Depth-of  -f ield table of MC Rokkor
       f nserting the mercury battery      ........7       50mm F1.4 and F1.7 lens (in meters)  . ..  . . 2g
 Checkingthebatterypower .........  9          Depth-of-field table of MC Rokkor
  Loading film .                               ... 10      58mm F1.2lens  (in feet)                           . . . .29
  Setting the ASA number  (f ilm speed)  . . . . . . 14          Depth-of-f ield table of MC Rokkor
 ASA/DIN converting scale .                ... 14      58mmF1.2lens(inmeters)  .......30
                                                   Checking the effects of depth of  f ield  . . . . . 31
TAKING PICTURES                            Self-timer                       .......32
 TTL with CLC: A new exposure                        Infrared index .                    ........33
  measuringsystem             ....15        Film plane index                       ...... 33
 Settingthecorrectexposure  ........  16     MULTIPLE EXPOSURES  ....         ....... 34
 Shutterspeed and aperturesettings ........  1B     UNLOAD|NG EXPOSED FtLM        ..... 34
  Focusing the camera                ...20     CHANGING LENSES                     ... 36
 Holding the camera                                      . ...21
                                        USING OTHER THAN MC
TAKING FLASH PICTURES     ...,..   , ,22     (METER.COUPLED) LENSES
 Att'aching flash unit                         ... .23       Auto Rokkor Lenses                                    . . .38
 Settingcorrectexposure       .....24        Manual presetRokkorLenses  ....... 39
MORE ADVANCED GI.'IDES                 CARE AND STORAGE
 Depth of  f ield
View original page 3
Page 6 · Read text
Rewind shaft
Film cartridge chamber
Finder eyepiece
Battery svvitch
Focal plane shutter
Tripod socket
Sprocket
Battery chamber cover
F ilm-advance release button
Film take-up spool
Film pressure plate
View original page 6
Page 7 · Read text
MAJOR FEATURES OF THE MINOLTA SR.T 303

 1. Better Through-the-Lens Exposure System     3. Multiple-Exposure  Capability
a) Exposure readings are taken with the lens at        Creative possibilities are greatly expanded
     full aperture for greatest metering accuracy      by the 303's ability to make multiple
   and best viewing and focusing.                       exposures simply and positively.
b) Since only the light to strike the film  is
    measured, there is no need to compensate  for    4. Direct-Contact "Hot Shoe"
     filters, greater-than-normal lens extension,        This accepts either cordless units or conven-
     etc.                                                       tional ones with cords.
c) The exclusive CLC metering system combines
   advantages of spot and averaging types to    5. World-Renowned Rokkor Lenses
    yeild optimum exposure even in  high-     MC Rokkor Lenses permit   f ull-aperture TTL
    contrast    I ighting situations.                           operation, while any other interchangeable
                                          Rokkor ever made can be used with the
 2.  " lnlormation-Center" Viewf inder                 stop-down method. Either way you benefit
a) Meter and follower needles in the viewf inder       from top Rokkor quality, computer design,
   show correct exposure setting at a glance.            and exclusive Achromatic coating.
b) Both shutter speed and F-number set are
    visible without taking your eye from the    6. Complete System Accessories
        fi nder.                          A full line of quality Minolta and adapted
c) Focusing virtually any kind of subject is         Leitz accessories makes for maximum versa-
    facilitated by the new focusing aid that           tility with the 303.
   employs a split-image spot and a microprism
    band.
View original page 7
Page 8 · Read text
www.butkus.us



 SPECIFICATIONS OF THE MINOLTA SR-T 303

-35 mm sin gle-lens-reflex ca mera with through-t he-lens exposure meteri ng-
standard lens MC Rokkor 50mm F 1.4 (F 1 .7 or 58mm F 1 .2) equipped with meter coupler
Composition:     7 elements in 5 groups
Coating:           Achromatic coating
Angle of iver:        47o with Somm lens (41o with S8mm lens)
Diaphragm:         Fully automatic
Diaphragmscale:  {.1.2l-,1.4,1'1.7l-,2,2.8,4,5.6,8,11,16withequa|-spaceandintermediateclick    F-stops
Filter/shade mount:  @SSmm,screw-in
Lens mount:         Minolta bayonet mount
Shutter Focal-plane type
Speeds:           8,1,112,114,118,1115,113O,1|ffi,11125,11250,U500,and1/1000sec.
Selector dial:          Single, non-spinning, equal-space, click stop dial
Sync. terminal:      Single terminal with X/FP selector switch
Self-timer:        Time adjustable, 10 sec. maximum delay
Film advance Lever type, quick advance winding with shutter cocking and double exposure prevention
Winding method:    Single-or multi ple*troke, with 2Oo lree clearance
Winding angle:      150"
Frame counter:     Automatic resetti ng counter showi ng number of exposed   f rames
Film rewinding:     Rapid rewinding with crank
Frame size:         36 x 24mm
Fif m:                Standard 35mm film,12,2Q, or 36 exposures
View original page 8
Page 9 · Read text
Viewfinder Real-image type through   fi xed, eye-level pentaprism; exposure-control needles (follower system),
battery check mark, shutter speed scale, and F-number visible in finder
Focusing screen: Mat Fresnel with a Q2.smm central horizontally oriented split-image spot surrounded
                   by a microprism band 1.Smm wide
Exposure meter Through-the-lens metering system
Exposure meter:  Contrast light compensator (CLC) with two CdS cells on the pentaprism
Measurement: Measuring at full aperture coupled to shutter speed, aperture and  f ilm speed setting
Control:          Follower-needle system viewed in the  f inder
Working range:  EV 3 to EV 17 with ASA 100 film
Diaphragm button: Depth-of-f ield preview button for MC Rokkor Lenses;measuring (stopdownl button for
                     other than MC Rokkor lenses
                                        39Film speed range:   ASA 6 -                               6400, DIN I -ASA setting:    On sh u tter speed dial; bu ilt-in ASA/D   I N conversion scale on camera back
Battery:           1.35v mercury battery, Mallory PX-625 or equivalent
Switch:        ON  , O F F, and battery check switch on base of camera
Focusing Bright-screen with micro-split and  fi ne ground glass
Focusing distance: 50cm (1.75 ft.) to inf inity
Focusing method: Direct helicoid focusing with infrared index
Mirror Oversize quick-return mirror
Others Built-in accessory hot shoe
Size and weight Body only
              Width 145mm 15-314"1; Depth 47.Smm{.1-718"1;Height95mm (3-314"1;71O9(25oz.l
(Rtt illustrations in this manual are with the F1.4 standard lens. There is, however, no
fundamental difference in use between this and the other interchangeable MC Rokkor Lenses.)
View original page 9
Page 11 · Read text
CAUTION:
  . Do not touch the batterv terminals with
   moist or dirty hands, as this can cause them to
   deteriorate and make the battery inoperative.
  . Do not discard a mercury battery in a fire or
   break it up.
 o When the camera is not being used, it  is
   advisable to turn the battery switch on the
   base of the camera to the "OFF" position,
  .  lf the camera is not to be used for over a
   month. remove the battery and store it in a
   dry, cool place.
 o Before putting the battery back in  the
   camera, clean both sides of the battery and
   the contact lead of the battery chamber with
   dry cloth.
View original page 11
Page 12 · Read text
www.butkus.us





Checking the battery power
The battery checker is designed to check the    2. lf the indicator needle points to the battery
output of the mercury battery. By taking a few       check mark as shown in the picture, the
seconds to check battery output before starting       battery can be regarded as functioning
each new roll of  f ilm, and particulary when using         properly.
the camera af ter  it has been stored for an
extended period of time or a new battery has    CAUTION:
been inserted, you can avoid poor exposure due     o Do nol leave switch settirrg at battefy check
to insufficient electric power.                            position as the continuous higlr battery drain
1. Turn the battery switch on the base of the          will cause the battery to go "deac.l" in a few
   camera to the "B.C." position.                             horr rs.


            rF6rF
View original page 12
Page 13 · Read text
10                    Loading  f ilm

                  1. Raise the back cover release knob
                      (which also incorporates the film rewind
                     knob) until some resistance is felt. With a
                           slight additional pull, the back cover will    2. Insert the film leader into a slot in the film
                         automatically "pop" open.                          take-up spool as shown.

                        ff,





                                                                                            www.butkus.us
View original page 13
Page 14 · Read text
www.butkus.us




                                          4. Operate the film advance lever in several
                                                    short strokes until the film has begun to
                                          wind firmly around the take-up drum and
3. Place thefilm cartridge into the film cartridge      both sides of the film perforations are
   chamber and push the back cover release        securely engaged with the teeth of the
   knob all the way down. (When inserting the        sprocket gear. lf the film advance lever locks
   film cartridge. its proiecting center drum       during this procedure, press the shutter
   must be placed in a downward position,)                release button and then continue.
View original page 14
Page 15 · Read text
't ')
                  5. Close the camera back once you are certain
                      that the film is winding securely on the
                      take-up spool and engaged with on both
                            sproc kets.                                6. Advance the film and oress the shutter release
                      Rotate the film rewind crank gently in the        button. Repeat this action until the number
                          direction of the arrow to make sure that the         "l"  appears at the arrow mark in the
                           film is flat against the pressure plate.                exoosure counter window.
View original page 15
Page 16 · Read text
t.                                                      www.butkus.us





                                                                                                                    13
       NOTE:
        o The frame counter indicates the number of
             pictures taken from 1 to 36.
        o The  f ilm advance lever has a total "throw" of
            17Oo; ol this distance, the first 209 have no
             effect on the  f ilm but are intended to provide
          a "free play" range through which the lever
        may be "offset" from the body for rapid
            shooting.
        o When the camera back is opened, the counter
           automatically resets itself to the start (S)
             position.
View original page 16
Page 17 · Read text
14                   Setting ASA number  (f ilm speed)
                      Lift and rotate the shutter speed dial until the
                     figure (6 to 6400) which corresponds with the
             ASA rating of your film is visible in the ASA
                  window.
              On the ASA dial the following figures are    ASA/D   I N conversion scale
                      printed: 6 . 10 '16 .25..50..100 ..2OO "400
                    ..800 ..1600 ..3200 ..6400.                 To convert DIN film speed to the corres-
                The dots (.) denote ASA B, 12,20,32,40,64,     ponding ASA value, use the conversion scale
                   80, 125,160, 250, 320, 500, 640,1000, 1300,     located on the back cover of the camera. (The
                   2000, 2600,4000, and 5200, respectively.             inner numbers are DlN.)
View original page 17
Page 18 · Read text
www.butkus.us



TAKING PICTURES                                                                                              15

TTL with CLC: A new exposure
measuring qfstem
  The Minolta SR-T 303 camera has a
through-the-lens measuring system with CLC
meter.
   Minolta's exclusive, revolutionary CLC
"Contrast Light Compensator" promises better
photographic results with multiple split expo-
sure measuring system.
   Under normal photo-taking conditions this
new system gives excellent results; under other
conditions, such as in high-contrast  scenes, the
CLC feature prevents possible photo failures.
View original page 18
Page 19 · Read text
Setting the correct exposure                   The shutter soeed set is indicated in the
                                                viewfinder beneath the frame, while the F-
  When aiming the camera at your subject    number of the aperture set appears above the
through the viewfi nder, you wil  I see the    i ndicator     frame.
needle moving. Once the indicator needle has
stopped moving, turn the shutter speed dial
and/or the diaphragm ring to align the follower
needle (circle-tipped needle) with the indicator
needle.





                                                                  www.butkus.us
View original page 19
Page 20 · Read text
www.butkus.us



  When the proper combination of aperture    CAUTION:
and shutter speed setting is made for correct    o When setting the aperture  f irst, be sure not to                 17
exposure, the follower needle (which is coupled          set the shutter speed between cl ick stops.
to the aperture, shutter speed, and ASA speed       . When the shutter speed is set slower than
settings) will align with the indicator needle over        1/30th sec., be extremely careful of camera
a range of EV 3 through EV 17 at ASA 100. The      motion while releasing the shutter. lt   is
EV range will vary with  f ilm speed.                  recommended that a tripod be used at speeds
     It is a recommended procedure to set the        of 1/3oth sec. or slower. For "Bulb" setting, a
shutter speed first (depending on the motion or        cable release should also be used.
lack of motion of your subject or the overall    o When using high-speed film, a shutter speed
lighting) and to then adjust the aperture.               of 1l2sOth sec. is recommended for outdoor
     lf the needle fails to move when the       photography, and 1 /30th sec. for indoor use.
diaphragm ring is rotated, this signals a need to    o When photographing a group of people or a
adjust your shutter speed setting.                        building requiring great depth of field, close
   Since F-number and shutter-speed  indi-      down the diaphragm as much as possible. See
cations as wellas meter and follower needlesare         the "depth of field" on page 25 for details.
continuously visible in the viewf inder, you can
make all exposure adjustments and know exactly
the settings you are making without taking the
camera away  f rom your eye.
View original page 20
Page 21 · Read text
Shutter speed and aperture settings                The figure of B and 1 through 100O on the
                                                                      shutter speed dial respectively indicate bulb
r8                   The shutter speed (the period of time during    action and shutter speeds from 1 to 1/1o00th
                 which the shutter remains open) works in    second. (At "8" the shutter will remain ooen
                     conjunction with the lens opening (aperture) to    until pressure is removed from the release
                    determine the amount of light striking the film,     button.)
                The higher the shutter speed, the more effec-      The aperture setting controls the light reach-
                        tively it will momentarily "stop" the action of    ing the film at any given shutter speed. ln
                    your subject.                                         addition,  it determines the "depth of  f ield." (See
               To set shutter speed, simply rotate the    page 25.)
                    shutter speed dial until the desired speed
                      indication is aligned with the index on the
                 camera bodv, or until it is centered between                     indicators on the shutter soeed scale in the         r                        viewf inder.
View original page 21
Page 22 · Read text
www.butkus.us


    The lens aperture ring is engraved with     passed increases. The theoretical relation be-
  F-numbers from maximum aperture through     tween aperture and light volume  is shown in the
  16. The lens opening  is set by rotating this until     diagram. In practice, this varies somewhat  at
  the desired number is aligned with the index (o    large or maximum apertures, but  your                 19
  or I  l or appears above the frame in the    SR-T 303 and MC Rokkor lenses have built-in
  viewf inder.                                    compensation for this to give you most satis-
    When other conditions remain constant, light     factory exposure.
  passing through a lens generally decreases 50
  percent for every full-stop increase in F-number    NOTE:
   (for example, when the aperture number of a fast    o "Click" stops are provided for half-stop
  lens is increased from F5,6 to F8. the light        aperture settings.  I ntermediate shutter speeds
  passing to the film decreases by 5O percent).             cannot be set.
   As the aperture figure decreases, the light     o The figure "B" on the shutter speed dial is
                                                  used when an exposure duration of over 1
     r.to.Ir.z  rr @                             opensecondwhileis required.the shutterThereleaseshutteris depressed.will remain
                                            o The red figure "60" on the shutter speed dialll'n"nT"t'""'vofume      g   2      |    t2    t{    t/8  tt6  t/32 t6a      indicates the maximum shutter speed to be
                                                      used in conjunction with electronic flash.
                                                                   . Since light striking the film is affected by a
                                                    combination of aperture and shutter speed,
                                                     exposure can be adjusted by changing either
                                                             or both of these settings.
                                                                   . The shutter speed at which the camera  is set
                                                  can be seen from the scale visible below the
                                                  frame in the viewfinder, With most lenses,
                                            the F-number set is displayed above the
                                                           viewfield in the  f inder.
View original page 22
Page 23 · Read text
Focusing the camera                      To focus using the split-image spot, look20
                                                                         through the viewfinder and turn the focusing ring        I                The focusing screen of  the M inolta   on the lens until the upper and lower images in
                   SR-T 303 has a central horizontally oriented    the split-image spot are exactly aligned with no          I
                         split-image spot surrounded by a circular micro-    broken lines between them.
                    prism band. You can choose either of these      For microprism focusing, turn the ring until
                        focusing aids according to the subject and your    the image is no longer broken up but appears
                        preference.                                               clear in the microprism band.


                              In focus                                      Out of focus




                                                                                                                                                                             I

                                                                                                                  J
View original page 23
Page 24 · Read text
www.butkus.us




        Holding the camera                          NOTE:
                                                                                                  against your face,                   21 I                                            o Pressing the camera gently        The camera may be held horizontally or       or supporting the elbow of the hand holding
 I       vertically. In either case, be sure to hold the      the camera against your body, will aid in
       camera in a comfortable position. This will help        steady holding.
       to prevent movement of the camera during    o The camera will tend to move more when
        exposure and avoid blurred pictures.                   used in the vertical position.





 I
I
View original page 24

From the M. Butkus archive. Original publisher and archive notices are retained.
Check the model and edition against your equipment.

PDF verified 2026-10-10.
