Mamiya RZ67 Pro II accessories User manual
User manual for Mamiya RZ67 Pro II accessories. 11 pages in English. Read the original PDF, download or print a copy without registration.
11 pagesEnglish2.7 MB PDF
Loading your manual…Open PDF directly
Document details
- Brand
- Mamiya
- Model / document
- Mamiya RZ67 Pro II accessories
- Document type
- User manual
- Language
- English
- Pages
- 11
- File size
- 2.7 MB
- Category
- Camera accessories
- Document date
- Not specified in catalog
Search available document text
Find a term, then jump to its page in the original PDF. Image-only pages may not be searchable; check the PDF for exact wording and diagrams.
Page 1 · Read text
www.butkus.us
ffiti
The versatility of the Mamiya RZ67 Professional II
has been greatly enhanced by a large selection of system accessories.
The major ones shown in this pamphlet. Please request the complete 24 page
RZ67 Professional II catalog which shows our entire accessory program.View original page 1Page 3 · Read text
Interchangeable Lenses Interchangeable Lenses There are 19 different RZ67 interchangeable lenses ranging f rom wide-angle and telephoto to the highest grade APO and other special use lenses: all of which feature excellent color balance, contrast and resolution based on the latest in optical theory and technology.View original page 3
Page 6 · Read text
www.butkus.us
Bellows Lens Hood G-3 Focusing Screens
Seven types are avaihble which can be changed according to
Bellows Lens Hood photographic requirements, lens used and subject.
G-3
Type A : Matte. Entirely matted with Fresnel lens. For general-
purpose photography.
Type A3: Matte with blacked out corners . Entirely matted with
Fresnel lens. Makes vertical/horizontal frames more
visible when revolving.
Type 44 : Checker. Entirely matted with Fresnel lens and 1Omm
sectional grip markings. ldeal for close-ups, copy
work and architectural applications.
Type B : Rangefinder spot. Entirely matted with Fresnel lens
and split-image center focusing aid which allows
Front Hood for the quick focusing.
G-3 Type C : Microprism. Entirely matted with Fresnel lens and mi-
croprism center focusing aid which allows quick fo-Utilizing gear driven side struts, instead of the customary cusing.
base rails, this best of all lens hoods can be used with lenses Type D : Cross-hair. Entirely matted with small, clear centerfrom 65-360mm and also 100-200mm Zoom lens (for which circle. For close-ups, etc., by means of parallax of thean optional adapter with rotation stopper is available). lf fea- center cross-hair, accurate focusing is possible for
tures a stage for 3" filters in the rear and a slot for standard close-up and other special work.
vignetters in the front frame. Type E : Rangefinder spot / microprism. Entirely matted withExtension from 50mm to 175mm. Weight 3359 Fresnel lens and split-image center focusing aid sur-
rounded with microprism. Focusing is possible with
Front Hood for the G-3 either the center split-image, microprism or peripheral
ls designed to attach to the front frame of the G3 Hood when matte screen.
used with a vignetting mask in order to shade it from direct
light. External Battery GaseExtension from 25mm to 105mm. Weight 1459
Used for cold weather photography, it permits battery to be worn
inside clothing. (Connects by wire to camera).View original page 6Page 7 · Read text
Roll Film Holders
There is a choice of four Roll Film
Holders and a Polaroid Holder, all
quickly interchangeable and all
featuring ISO film index dials,
which interface holders with cam-
era, AE Prism Finder and lenses.
Performance Table
120 Roll Film 220 Roll Flm 6x6 120t220Roll Film 6x4.5 12() Roll Film Polaoil Pack Film
Holder RZ Hokhr RZ Hoftler HFIO2
Hoker HATUI Holder HB7@ (wih geod fndermask) (with special finder mask)
Filrntypo 120 ollfilm 220 ollfilm 120 or 220 roll film 120 ollfilm Polamid 100. 660 Series.
PixuE bmat 6xTcmfonnat 6xTcmtormat 6rScmformal 6 x 4.5 cm lbrmal TxTcmh||mal
(56 x 69.5 mm) (56 x 69.5 mm) (56 x 56 mm) (56 x 41.5 mm) (69.5 r &9.5 mm)
Number 10 20 12(1201or24(n0\ IE nololpoqil€s
Film adance (canBy alsomeansbe ofadvancedthe ockingby theleverfilmonadvancelhe cameraknob bodyon lh€ holder) (f ilm separation)Peel aoart system
. Film speed (lSO 25€,a00) dral (speed value coupling with finder and built-in exposure meter). Multiple exposure Film speed dial (speed value
olher fedures plevention system (multiple exposures possible) . AulonElically resetlable exposure counter. Daft slide prevented coupling wilh the finder and
from moving out ol place. Dark slide sloring lug. buift-in exposuE meter)
5009 500s 550s 5050
120 Roll Film Holder HA703 and 220 Roll Film Holder HB702 have two exposure counter windowsView original page 7Page 8 · Read text
l€
Focusing Screens www.butkus.us
Seven types are available which can be changed according to
photographic requirements, lens used and subject.
Type A : Matte. Entirely matted with Fresnel lens. For general-
purpose photogrlphy.
Type A3: Matte with blacked out corners . Entirely matted with
Fresnel lens. Makes vertical/horizontal frames more
visible when revolving.
fype n+ , Cl'recker. Entirely ratteO *itft fresnet tens anO
sectional grip markings. ldeal for close-ups, copy
work eE irchiectyral applications.
Type B : Rangefinder spot. Entirely ratteO *itf' fr".n"f le,ns
and split-image center focusing aid which allows
quick focusing.
Type C : Microprism. Entirely matted with Fresnel lens and mi-
croprism center focusing aid which allows quick fo- (
cusing.
'l Type D : Cross-hair. Entirely matted with small, clear center
circle. For close-ups, etc., by means of parallax of the t
center cross-hair, accurate focusing is possible for (
close-up and other special work. 'l
Type E : Rangefinder spot / microprism. Entirely matted with
Fresnel lens and split-image center focusing aid sur-
rounded with microprism. Focusing is possible with
either the center split-image, microprism or peripheral
matte screen.
External Battery Case
Used for cold weather photography, it permits battery to be worn
inside clothing. (Connects by wire to camera).View original page 8Page 9 · Read text
Power Winder RZ Model 2
Attaching ergonomically to the camera's tripod
socket, the Power Winder 2 advances the film auto-
matically and simultaneously cocks the mirror and
shutter. Optional radio and infrared remote controls
are available for off camera operation. Single or se-
quence exposures. Speed approx. 1,5 frames/sec.
Power source : 6 AA alkaline or Ni-cd batteries (for
about 30 rolls of 120 film). Optional 9V AC adapter.
Dimensions 100 x 95 x 43mm. Weight 5509. without
batteries.
Electromagnetic Cable Release
These wire release attach and lock to
the camera's electronic shutter release
contacts. Available in two lengths:
Type A 1m coil cord. Type B 4m.
T
z Mirror-up Cable Release p
C
A double function cable release which first moves and locks the mirror in the c
up position and then releases shutter. VView original page 9Page 11 · Read text
Magnifier FD701 This magnifier attaches to the eyepiece of the prism finder and swings out of the way when not in use. lt magnifies the center portion of the image and makes critical focusing very easy. Built in diopter adjustment from -6 to +4. Optical design: 4 lens elements in 2 groups. Magnification : 2.4 (telephoto) Diopter correction range : -6 - +4 lmage : Unreversed laterally correct image Weight:709 Teleconverter RZ1.4x Increases the focal length of lenses from 90mm up by 1.4 x, while maintaining exellent image quality. Thus the 100-200mm Zoom lens becomes 140- 280mm. Also couples automatically with lens dia- phragm. Optical design: 5 lens elements in 3 groups. Dimension : 37mm diameter x 97.2mm. Weight:4309View original page 11
