Page 4 · Read text

ATTACHINGYOUR
       QU|CKFOCUSLEVER



The illustrationshows the Quick Focus Lever
mountedin the most-usedposition.Set the fo-             Focus Lever
cusingringon the cameraat the infinitypositlon.
Back off the knurled adjustingscrew on the FocusLever and orient it to the
cameraas shown.Two lugs on the insidediameterof the FocusLevershould
face upward, away from the camera.Align the lugs with two of the knurled
finger-gripindentson the focusing ring. Pressthe Focus Lever on the ring,
seatingit flush to the shoulderof the ring.Tightenthe knurledadjustingscrew.

Notethat the mountingis not limitedto the positionshown.The FocusLever
can be mountedin any positionmost convenientfor you!
