Minolta Electronic Power Winder User manual

SPECIFICATIONS
Camsn: Fits all "X" series (X-70O, etc.l and
      "XG" series (XG-A, etc.) cameras
Winding Speed: Approx.2 frames per second
Wind Modes:
                                 Possible with        "Off" - Manual wind               winder attached
       "C" -  Continuoussequence orsingle               frame
          ',S"    Single frame only ("X" series/              -           XG-M cameras)
 Power Source': 4 AA batteries (Alkaline
        recommended)
 Battery Life: Approx.6O  rolls 36 exposure
         film (Alkaline batteries)
 Shutter Sped Range: All speeds plus Auto
         or Program
 Automatic Cut-off Circuit: Winding stops
         automatically at film end
 Rewind Ind'rcation: Red LED lights at film
        end
 Power On Indication: Green LED lights
       when pwver is on

www.butkus.us
   PARTS IDENTIFICATION





                                                        butkusmike
                                                   ou=29,                                           DigitallyDN:o=orphancameras,email=mike@butkus.org,Date:cn=mike2019.01.08signedbutkus,by17:22:36mikebutkus                        c=US-05'00'


              9 1012 11
     1. Guide Pin
    2. Winder Coupler
    3. Coupling Screw
    4. Contact Pins
    5. Tripod Socket
    6. Banery Compartment Cover
     7. Rewind Indicator
     8. Power On Indicator
      ' 9. Remote Socket   10. Main Switch
   11. Film Rewind Button   *12. lnterval Timer Switch

Winding Mode Positions for X-series
 and XG-M Gemoras.
 Note: these cameras are able to send a
 special signal to the winder causing it
 to stop after each picture when the main
 switch is set to "S" position. Of course
 continuous seguence pictures are also
 possible at the "C" position.
   Raird@On
  O    Renrore


Winding Mode Positions
XG-Series oameras.
Note: these cameras are not able to
provide any of the special signals required
for "S" single frame mode. They can
only operate in the "C", continuous
sequence position or "T" time delay
position.

SPECIAL FEATURES
(not available on all winder modelsl
Remote Control
 lf your winder has this feature, picturcs
can be taken by remote control by plugging
the optional remote switch into the
 "Remote" socket on the winder. The
 winder will operate in the same manner as
 if using the shutter release on the camera.
The remote switch will only function
 correctly with the "X" series cameras.
Remote control shooting is poesible with
the other "XG' model oameras by using
a special remote cable release provided
by Minolta which can fasten directly to the
camera body.

Time Delay Photography
Winder models equipped with this feature
can be used to take a continuous sequenoe
of pictures with a timed interval between
each picture.
1. Set the main function switch to "T".
2. Set the interval timer switch to the
    desired time setting.
   NOTE:
   The exact time delay will rrary depending
   on battery type and condition.
3. Using a locking type cable release,
    press the shutter release and lock at to
    'start the picture sequence.
4. To stop the picture sequence, unlock
   the cable release and turn the winder
    "o(f".
