Singer 101-1 — Parts list

INSTRUCTIONS FOR ORDERING


  In ordering from  this  list, use ONLY the part NUMBER
in the FIRST column.
  The number stamped on a Sewing Machine part  is in every
case the number of the single part only.
  Every combination of parts sent out as such has its specific
number, which, although not stamped on the parts, must be
used when ordering the combination.
  Each number always indicates the SAME PART in whatever
list it appears, or for whatever machine.
  The letters after some of the numbers indicate the style of
finish only. as follows:
               Hardened, Polished and Plated,
                Polished and Plated
              Hardened only.
                 Polished only.
                   Soft. not Polished.
              Hardened and Polished.

               Blued
                Plated only.
              Hardened and Plated.
                Brass or Gilt.                 zrzsmpsspcee.  Oxidized.
             P.  J apanned,
           R.  Parkerized.
  These letters MUST BE USED when they appear in the list,
and AFTER the number as in the list.
   In this series
              1 to 1500 and 50001 to 51500 are Screw Numbers.
       1501 to 1800 are Nut Numbers,
       1801 to 2000 are Roller Numbers.
       2001 to 50000 and 52001 and upward  are numbers  of
          Machine Parts.
  The figures  in  the second column  refer only  to the  plates,
illustrating the parts, and are NOT TO BE USED in ordering.
  Parts marked with an asterisk  (‘) are furnished only when
repairs are made at factory.
